Liu Jiang, Jia Li, Zeng Minghui, Xu Hao, Zhang Rui, Pang Qi
Department of Neurosurgery, Shandong Provincial Hospital, Shandong University, Ji'nan, Shandong, 250021, China.
Department of Neurosurgery, The First Affiliated Hospital of USTC, Division of Life Sciences and Medicine, University of Science and Technology of China, Hefei, Anhui, 230001, China.
Heliyon. 2024 Jul 25;10(15):e34924. doi: 10.1016/j.heliyon.2024.e34924. eCollection 2024 Aug 15.
OBJECTIVE: To describe the feasibility, safety and efficacy of mobilization of the vertebral artery for C2 pedicle screws in cases with the high-riding vertebral artery (HRVA). .
During the period January 2020 to September 2022, fifteen patients underwent posterior occipitocervical fixation in our department. All patients had unilateral HRVA on at least one side that prohibited the insertion of C2 pedicle screws. There were 2 males and 13 females aged 47 ± 11.9 years (range: 17-64 years). After the correction of the vertical dislocation during the operation, the C2 pedicle screw insertion and occipitocervical fixation and fusion were performed using the vertebral artery mobilization technique. A routine three-dimensional reconstructed CT examination was executed to confirm the trajectory of C2 pedicle screws post-operation, and a CT angiography examination was performed when necessary. Neurological function was assessed using the Japanese Orthopedic Association (JOA) scale. The preoperative and postoperative JOA score and the main radiological measurements, including anterior atlantodental interval (ADI), the distance of odontoid tip above Chamberlain line, and clivus-canal angle (CCA), were collected and compared by paired -test.
All 15 patients had atlas assimilation, among which 12 patients had C2-C3 fusion (Klippel-Feil syndrome). Mobilization of the HRVA was successfully completed, and C2 pedicle screws were then fulfilled after the vertebral artery was protected. There was no injury to the vertebral artery during the operation. Meanwhile, no severe surgical complications such as cerebral infarction or aggravated neurological dysfunction occurred during the perioperative period. Satisfactory C2 pedicle screw placement and reduction were reached in all 15 patients. All the patients achieved bone fusion 6 months after surgery. No looseness and shift of internal fixation or reduction loss was observed during the follow-up period. Compared to the preoperative, the postoperative JOA score and the main radiological measurements were remarkably improved and statistically significant.
C2 pedicle screw insertion assisted by mobilization of the vertebral artery is safe and considerably effective, providing a choice for internal fixation in cases with high-riding vertebral arteries.
描述在椎动脉高位(HRVA)情况下,椎动脉移位辅助置入C2椎弓根螺钉的可行性、安全性和有效性。
在2020年1月至2022年9月期间,我科对15例患者进行了枕颈后路固定术。所有患者至少一侧存在单侧HRVA,这使得C2椎弓根螺钉无法置入。患者年龄47±11.9岁(范围:17 - 64岁),其中男性2例,女性13例。术中在纠正垂直脱位后,采用椎动脉移位技术进行C2椎弓根螺钉置入及枕颈固定融合。术后常规行三维重建CT检查以确认C2椎弓根螺钉的轨迹,必要时行CT血管造影检查。采用日本骨科协会(JOA)评分评估神经功能。收集术前和术后的JOA评分以及主要影像学测量数据,包括寰齿前间隙(ADI)、齿突尖高于Chamberlain线的距离以及斜坡 - 椎管角(CCA),并通过配对检验进行比较。
15例患者均存在寰椎融合,其中12例患者存在C2 - C3融合(Klippel - Feil综合征)。成功完成了HRVA的移位,在保护椎动脉后完成了C2椎弓根螺钉的置入。术中椎动脉无损伤。同时,围手术期未发生脑梗死或神经功能加重等严重手术并发症。15例患者C2椎弓根螺钉置入位置及复位均满意。所有患者术后6个月均实现了骨融合。随访期间未观察到内固定松动、移位或复位丢失。与术前相比,术后JOA评分及主要影像学测量数据均有显著改善且具有统计学意义。
椎动脉移位辅助下的C2椎弓根螺钉置入安全且相当有效,为椎动脉高位患者的内固定提供了一种选择。
