The enhanced permeability and retention (EPR) effect controls passive nanodrug uptake in tumors and may provide a high tumor payload with prolonged retention for cancer treatment. However, EPR-mediated tumor uptake and distribution vary by cancer phenotype. Thus, we hypothesized that a companion PET imaging surrogate may benefit EPR-mediated therapeutic drug delivery. We developed two 89Zr-radiolabeled nanocarriers based on 4-armed starPEG40kDa with or without talazoparib (TLZ), a potent PARP inhibitor, as surrogates for the PEG-TLZ4 therapeutic scaffold. For PET imaging, PEG-DFB4 and PEG-DFB1-TLZ3 were radiolabeled with 89Zr by replacing one or all four copis of TLZ on PEG-TLZ4 with deferoxamine B (DFB). The radiolabeled nanodrugs [89Zr]PEG-DFB4 and [89Zr]PEG-DFB1-TLZ3 were tested in vivo in prostate cancer subcutaneous (s.c.) xenografts (22Rv1, LTL-545, and LTL-610) and 22Rv1 metastatic models. Their EPR-mediated tumoral uptake and penetration was compared with CT26, a known EPR-high cell line. MicroPET/CT images, organ biodistribution, and calculated kinetic parameters showed high uptake in CT26 and LTL-545 and moderate to low uptake in LTL-610 and 22Rv1. MicroPET/CT and high-resolution autoradiographic images showed nanocarrier penetration into highly permeable CT26, but heterogeneous peripheral accumulation was observed in LTL-545, LTL-610, and 22Rv1 s.c. xenografts and metastatic tumors. CD31 staining of tumor sections showed homogenous vascular development in CT26 tumors and heterogeneity in other xenografts. Both [89Zr]PEG-DFB4 and [89Zr]PEG-DFB1-TLZ3 showed similar accumulation and distribution in s.c. and metastatic tumor models. Both nanocarriers can measure tumor model passive uptake heterogeneity. Although heterogeneous, prostate cancer xenografts had low EPR. These starPEG nanocarriers could be used as PET imaging surrogates to predict drug delivery and efficacy.
