Kasai Yuhei, Kitai Takayuki, Morita Junji, Fujita Tsutomu
Department of Cardiology, Sapporo Heart Center, Sapporo Cardiovascular Clinic, Sapporo, Japan.
Indian Pacing Electrophysiol J. 2025 Mar-Apr;25(2):118-121. doi: 10.1016/j.ipej.2025.02.004. Epub 2025 Feb 12.
Cavotricuspid isthmus (CTI)-dependent atrial flutter (AFL) is difficult to manage with antiarrhythmic drugs, with radiofrequency (RF) ablation being the standard treatment. However, achieving a bidirectional CTI block can be challenging due to complex anatomy and epicardial-endocardial breakthrough (EEB). This case report illustrates that cryoablation can serve as an effective bail-out strategy to achieve a permanent CTI block when RF ablation fails, particularly in cases complicated by EEB. We present the case of a 66-year-old woman who underwent multiple catheter ablations for persistent atrial fibrillation (AF) and CTI-dependent AFL. Despite two prior sessions of RF-based CTI ablation, a durable bidirectional block was not achieved. During her fourth ablation, recurrent AFL persisted despite extensive RF applications. Cryothermal ablation, utilizing a Freezor MAX catheter with point-by-point freezing along the CTI line, successfully terminated the AFL and created a durable bidirectional CTI block. While RF ablation remains the primary treatment for CTI-dependent AFL, the formation of a durable bidirectional CTI block can be challenging due to complex CTI anatomy, EEB, and tissue edema. Cryothermal ablation offers a viable alternative in these difficult cases. The enhanced tissue adhesion and improved catheter stability provided by cryoablation, along with the reduced risk of steam pops, allow for more consistent lesion formation. This case underscores the utility of cryoablation as a bail-out strategy when RF ablation alone is insufficient.
依赖腔静脉三尖瓣峡部(CTI)的心房扑动(AFL)使用抗心律失常药物难以控制,射频(RF)消融是标准治疗方法。然而,由于解剖结构复杂和心外膜 - 心内膜突破(EEB),实现双向CTI阻滞可能具有挑战性。本病例报告表明,当RF消融失败时,冷冻消融可作为一种有效的补救策略来实现永久性CTI阻滞,特别是在合并EEB的病例中。我们报告一例66岁女性,她因持续性心房颤动(AF)和依赖CTI的AFL接受了多次导管消融。尽管之前进行了两次基于RF的CTI消融,但未实现持久的双向阻滞。在她的第四次消融过程中,尽管广泛应用RF,复发性AFL仍持续存在。使用Freezor MAX导管沿CTI线逐点冷冻的冷冻消融成功终止了AFL并创建了持久的双向CTI阻滞。虽然RF消融仍然是依赖CTI的AFL的主要治疗方法,但由于CTI解剖结构复杂、EEB和组织水肿,形成持久的双向CTI阻滞可能具有挑战性。冷冻消融在这些困难病例中提供了一种可行的替代方法。冷冻消融提供的增强的组织粘附力和改善的导管稳定性,以及降低的蒸汽泡风险,允许形成更一致的病变。本病例强调了冷冻消融作为单独RF消融不足时的补救策略的实用性。
