结合多注意力机制的高效卷积网络模型用于荷斯坦奶牛个体识别

Efficient Convolutional Network Model Incorporating a Multi-Attention Mechanism for Individual Recognition of Holstein Dairy Cows.

作者信息

Ma Xiaoli, Yu Youxin, Zhu Wenbo, Liu Yu, Gan Linhui, An Xiaoping, Li Honghui, Wang Buyu

机构信息

College of Computer and Information Engineering, Inner Mongolia Agricultural University, Hohhot 010018, China.

Key Laboratory of Smart Animal Husbandry, Universities of Inner Mongolia Autonomous Region, Hohhot 010018, China.

出版信息

Animals (Basel). 2025 Apr 19;15(8):1173. doi: 10.3390/ani15081173.

Abstract

Individual recognition of Holstein cows is the basis for realizing precision dairy farming. Current machine vision individual recognition systems usually rely on fixed vertical illumination and top-view camera perspectives or require complex camera systems, and these requirements limit their promotion in practical applications. To solve this problem, a lightweight Holstein cow individual recognition feature extraction network named CowBackNet is designed in this paper. This network is not affected by camera angle and lighting changes and is suitable for farm environments. Secondly, a fusion multi-attention mechanism approach was adopted to integrate the attention mechanism, inverse residual structure, and depth-separable convolution technique to design a new feature extraction module, LightCBAM. This module was placed in the corresponding layer of CowBackNet to enhance the model's ability to extract the key features of the cow's back image from different viewpoints. In addition, the CowBack dataset was constructed in this study to verify the model's ability to be applied in real scenarios, containing Holstein cowback images in real production environments under different viewpoints. The experimental results show that when using CowBackNet as a feature extraction network, the recognition accuracy reaches 88.30%, FLOPs are 0.727 G, and the model size is only 6.096 MB. Compared with the classical EfficientNetV2, the accuracy of CowBackNet is improved by 11.69%, the FLOPs are reduced by 0.001 G, and the number of parameters is also reduced by 14.6%. Therefore, the model developed in this paper shows good robustness in shooting angle, light change, and real production data, which not only improves the recognition accuracy but also optimizes the computational efficiency of the model, which is of great practical application value for realizing precision farming.

摘要

荷斯坦奶牛个体识别是实现精准奶牛养殖的基础。当前的机器视觉个体识别系统通常依赖固定的垂直照明和顶视图相机视角,或者需要复杂的相机系统,而这些要求限制了它们在实际应用中的推广。为了解决这个问题,本文设计了一种名为CowBackNet的轻量级荷斯坦奶牛个体识别特征提取网络。该网络不受相机角度和光照变化的影响,适用于农场环境。其次,采用融合多注意力机制方法,将注意力机制、逆残差结构和深度可分离卷积技术相结合,设计了一种新的特征提取模块LightCBAM。该模块被放置在CowBackNet的相应层中,以增强模型从不同视角提取奶牛背部图像关键特征的能力。此外,本研究构建了CowBack数据集,以验证模型在实际场景中的应用能力,该数据集包含不同视角下实际生产环境中的荷斯坦奶牛背部图像。实验结果表明,当使用CowBackNet作为特征提取网络时,识别准确率达到88.30%,FLOPs为0.727 G,模型大小仅为6.096 MB。与经典的EfficientNetV2相比,CowBackNet的准确率提高了11.69%,FLOPs减少了0.001 G,参数数量也减少了14.6%。因此,本文开发的模型在拍摄角度、光照变化和实际生产数据方面表现出良好的鲁棒性,不仅提高了识别准确率,还优化了模型的计算效率,对实现精准养殖具有重要的实际应用价值。
