Dasca Beneito Ariadna, Andreo Acosta Andrés Alberto, Sierra Andrés F, Blondeau Pascal, Ballester Pablo, Riu Jordi, Andrade Francisco Javier
Dept. Química Analítica i Química Orgànica, Universitat Rovira i Virgili (URV), Carrer de Marcel·lí Domingo, 1, 43007 Tarragona, Spain.
Institute of Chemical Research of Catalonia (ICIQ), Av. Països Catalans, 16, 43007 Tarragona, Spain.
ACS Omega. 2025 Aug 5;10(32):36475-36480. doi: 10.1021/acsomega.5c04973. eCollection 2025 Aug 19.
A novel paper-based ion-selective organic electrochemical transistor (IS-OECT) for the detection of potassium and creatinine is presented. First, ion-selective membranes are cast onto thick-film transistor channels to create highly sensitive and selective ion sensors. Since optimum performance is obtained at 0 V gate voltage, several sensors can be used in parallel with a single gate connected to a common grounded source electrode. Then, to further demonstrate the detection capabilities, the IS-OECTs were integrated with a purposely designed differential amplifier. This allows the conversion of current signals into a voltage output, facilitating comparison with potentiometric systems and the use of low-cost commercial data acquisition platforms. The evaluation of the performance in artificial serum is performed in clinically relevant ranges, which comprise 2.4-5.75 mM for potassium and 30-140 μM for creatinine. These results highlight the potential of the IS-OECT framework as a cost-effective, portable, and reliable solution for point-of-care diagnostics.
本文介绍了一种用于检测钾和肌酐的新型纸基离子选择性有机电化学晶体管(IS-OECT)。首先,将离子选择性膜浇铸在厚膜晶体管通道上,以创建高灵敏度和选择性的离子传感器。由于在0 V栅极电压下可获得最佳性能,因此多个传感器可与连接到公共接地源电极的单个栅极并联使用。然后,为了进一步展示检测能力,将IS-OECT与专门设计的差分放大器集成在一起。这允许将电流信号转换为电压输出,便于与电位系统进行比较,并使用低成本的商业数据采集平台。在临床相关范围内对人工血清中的性能进行评估,钾的范围为2.4-5.75 mM,肌酐的范围为30-140 μM。这些结果突出了IS-OECT框架作为一种经济高效、便携且可靠的即时诊断解决方案的潜力。
