Ohta Shinichi, Nitta Norihisa, Takahashi Masashi, Murata Kiyoshi, Tabata Yasuhiko
Department of Radiology, Shiga University of Medical Science, Shiga, Japan.
Korean J Radiol. 2007 Sep-Oct;8(5):418-28. doi: 10.3348/kjr.2007.8.5.418.
To investigate the basic characteristics of degradable gelatin microspheres (GMSs), including their embolic behavior and degradation periods when they are used as embolic materials in the renal arteries of rabbit models.
Based on the GMS particle size, 24 kidneys were divided into 3 groups of eight kidneys, and each group was embolized with a different GMS particle size (group 1: 35-100 microm, group 2: 100-200 microm, and group 3: 200-300 microm). From each group, two rabbits were sacrificed immediately after embolization (day 0), and a pair of rabbits from each group underwent an angiogram and were sacrificed on days 3, 7, and 14, respectively, after embolization. The level of arterial occlusion, the pathological changes in the renal parenchyma, and the degradation of the GMSs were evaluated angiographically and histologically.
A follow-up angiogram on days 0, 3, 7, and 14 revealed the presence of wedge-shaped poorly-enhanced areas in the parenchymal phase as seen in all groups. The size of these areas tended to increase with the particle diameter, and persisted up to day 14. On days 3, 7, and 14, parenchymal infarctions were observed histologically in all cases, and this observation corresponded with the parenchyma being supplied by the embolized arteries. GMSs of group 1 mainly reached the interlobular arteries, while those of group 3 mainly reached the interlobar arteries. In all but two cases, the GMSs were identified histologically even on day 14, and sequential degradation was histologically identified in all GMS groups.
GMSs can be used as degradable embolic materials which can control the level of embolization.
研究可降解明胶微球(GMSs)的基本特性,包括其作为栓塞材料应用于兔肾动脉模型时的栓塞行为和降解周期。
根据GMS粒径,将24个肾脏分为3组,每组8个肾脏,每组分别用不同粒径的GMS进行栓塞(第1组:35 - 100微米,第2组:100 - 200微米,第3组:200 - 300微米)。每组中,两只兔子在栓塞后立即处死(第0天),每组另外两只兔子在栓塞后第3天、第7天和第14天分别进行血管造影并处死。通过血管造影和组织学评估动脉闭塞程度、肾实质的病理变化以及GMSs的降解情况。
在第0天、第3天、第7天和第14天进行的随访血管造影显示,所有组在实质期均出现楔形强化减弱区域。这些区域的大小倾向于随粒径增大而增加,并持续至第14天。在第3天、第7天和第14天,所有病例组织学上均观察到实质梗死,且这一观察结果与栓塞动脉所供应的实质相符。第1组的GMS主要到达小叶间动脉,而第3组的主要到达叶间动脉。除两例外,即使在第14天,组织学上仍可识别出GMSs,并且在所有GMS组中均组织学鉴定出了连续降解。
GMSs可作为可降解栓塞材料,能够控制栓塞水平。
