标本尺寸会影响肌腱束中材料性能的测量。

Specimen dimensions influence the measurement of material properties in tendon fascicles.

机构信息

School of Engineering and Materials Science, Queen Mary University of London, Mile End Road, London E14NS, UK.

出版信息

J Biomech. 2010 Aug 26;43(12):2274-80. doi: 10.1016/j.jbiomech.2010.04.040. Epub 2010 May 18.

Abstract

Stress, strain and modulus are regularly used to characterize material properties of tissue samples. However, when comparing results from different studies it is evident the reported material properties, particularly failure strains, vary hugely. The aim of our study was to characterize how and why specimen length and cross-sectional area (CSA) appear to influence failure stress, strain and modulus in fascicles from two functionally different tendons. Fascicles were dissected from five rat tails and five bovine foot extensors, their diameters determined by a laser micrometer, and loaded to failure at a range of grip-to-grip lengths. Strain to failure significantly decreased with increasing in specimen length in both rat and bovine fascicles, while modulus increased. Specimen length did not influence failure stress in rat tail fascicles, although in bovine fascicles it was significantly lower in the longer 40 mm specimens compared to 5 and 10mm specimens. The variations in failure strain and modulus with sample length could be predominantly explained by end-effects. However, it was also evident that strain fields along the sample length were highly variable and notably larger towards the ends of the sample than the mid-section even at distances in excess of 5mm from the gripping points. Failure strain, stress and modulus correlated significantly with CSA at certain specimen lengths. Our findings have implications for the mechanical testing of tendon tissue: while it is not always possible to control for fascicle length and/or CSA, these parameters have to be taken into account when comparing samples of different dimensions.

摘要

压力、应变和模量常用于描述组织样本的材料特性。然而,当比较来自不同研究的结果时,很明显报告的材料特性,特别是失效应变,差异很大。我们的研究旨在描述为什么和如何,样本长度和横截面积(CSA)似乎会影响来自两种功能不同的肌腱的束中的失效应力、应变和模量。从五只大鼠尾巴和五只牛脚伸肌中解剖出束,用激光测微计测量其直径,并在一系列夹持长度下加载至失效。在大鼠和牛束中,随着样本长度的增加,失效应变显著降低,而模量增加。在大鼠尾巴束中,样本长度不影响失效应力,尽管在牛束中,40mm 长的样本的失效应力明显低于 5mm 和 10mm 长的样本。失效应变和模量随样本长度的变化主要可以用末端效应来解释。然而,也很明显,即使在距离夹持点超过 5mm 的位置,样本长度上的应变场也高度变化,并且在样本的末端处明显大于中部。在某些样本长度下,失效应变、应力和模量与 CSA 显著相关。我们的研究结果对肌腱组织的力学测试有影响:虽然不可能总是控制束的长度和/或 CSA,但在比较不同尺寸的样本时,必须考虑这些参数。

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/e838/2935962/bb48b3022bef/gr1.jpg
