Department of Orthopaedics, St. Olav's University Hospital, Trondheim, Norway.
Acta Orthop. 2010 Aug;81(4):427-35. doi: 10.3109/17453674.2010.501748.
We have developed an individually designed, uncemented femoral component for achievement of improved strain distribution and fixation to the bone, to make uncemented stems more applicable in femurs of abnormal size and shape, and to improve the joint mechanics. Here we describe the design of the implant and present the results of a prospective clinical study with at least 7 years of follow-up.
The prostheses are produced by CAD-CAM technique. The design of the stem is based on CT information, and the neck design is based on the surgeon's planning of the center of rotation, femoral head offset, and leg length correction. The first-generation stem produced before 2001 had a proximal HA coating and a sand-blasted distal part that was down-scaled to avoid contact with compact bone. The second-generation stem had a porous coating beneath the HA layer and the distal part of the stem was polished. The implant was used in 762 hips (614 patients) from 1995 until 2009. 191 of these hips were followed for 7 years and 83 others were followed for 10 years, and these hips are included in the present study. Mean age at surgery was 48 (20-65) years. Congenital dysplasia of the hip was the reason for osteoarthritis in 46% and 57% of the hips in respective groups. Merle d'Aubigné score was recorded in 152 and 75 hips in the two groups. Prostheses followed for 10 years, and almost all in the 7-year group, were first-generation stems.
The 7- and 10-year cumulative revision rates were 1.1% and 2.4%, respectively, with stem revision for any reason as endpoint. The clinical results were similar at 7 and 10 years, with Merle d'Aubigné scores of 17. Intraoperative trochanteric fissures occurred in 2 of the 191 operations (1.0%); both healed after wiring. In hips followed for 7 years, 2 periprosthetic fractures occurred; exchange of the stem was necessary in both. One additional fracture occurred between 7 and 10 years, and it was treated successfully with osteosynthesis. The rate of dislocation was 1.6% and 2.4%, respectively. There was no radiographic loosening at follow-up.
Use of a custom femoral stem gives a reliable fixation and promising medium-term clinical results in femurs of normal and abnormal shape and dimension. The individual design, which enables optimized joint mechanics, gives a low risk of mechanical complications.
我们开发了一种个体化设计的非骨水泥股骨假体,旨在改善骨固定的力学分布,使其更适用于尺寸和形状异常的股骨,并改善关节力学。本文描述了假体的设计,并介绍了一项前瞻性临床研究结果,该研究至少随访 7 年。
假体采用 CAD-CAM 技术制造。假体柄的设计基于 CT 信息,颈的设计基于术者对旋转中心、股骨头偏心距和下肢长度校正的规划。第一代假体在 2001 年之前生产,具有近端 HA 涂层和喷砂处理的远端部分,其缩径设计避免与密质骨接触。第二代假体具有 HA 层下的多孔涂层,假体的远端部分经过抛光。1995 年至 2009 年期间,该假体应用于 762 髋(614 例患者)。其中 191 髋随访 7 年,83 髋随访 10 年,这些髋关节均纳入本研究。手术时的平均年龄为 48 岁(20-65 岁)。髋关节先天性发育不良是导致 46%和 57%髋关节发生骨关节炎的原因。两组中分别有 152 髋和 75 髋记录了 Merle d'Aubigné 评分。随访 10 年的几乎均为第一代假体,而随访 7 年的假体中第一代和第二代假体各占一半。以任何原因翻修为终点,7 年和 10 年的累计翻修率分别为 1.1%和 2.4%。7 年和 10 年时临床结果相似,Merle d'Aubigné 评分为 17 分。191 髋中有 2 髋术中发生大转子骨折(1.0%),均经钢丝环扎固定后愈合。随访 7 年时,2 髋发生假体周围骨折,均需翻修假体。1 髋在随访 7-10 年时发生 1 处骨折,经骨愈合治疗后成功。脱位率分别为 1.6%和 2.4%。随访时无影像学松动。
个体化股骨假体在正常和异常形态及尺寸的股骨中能提供可靠的固定和有前景的中期临床结果。个体化设计可优化关节力学,降低机械并发症风险。
