Wayne State University School of Medicine, Detroit, MI, USA.
J Appl Clin Med Phys. 2010 Jul 2;11(4):3245. doi: 10.1120/jacmp.v11i4.3245.
The objective was to compare the dosimetry of Helical TomoTherapy (TOMO) and Gamma Knife (GK) treatment plans for tumor and normal brain in the treatment of single and multiple brain tumors. An anthropomorphic Rando Head phantom was used to compare the dosimetry of TOMO and GK. Eight brain tumors of various shapes, sizes and locations were used to generate 10 plans. The radiation dose was 20 Gy prescribed to the 100% isodose line for TOMO plans and to the 50% for the GK plans. Dose Volume Histograms for tumor and brain were compared. Equivalent Uniform Dose (gEUD), Tumor Control Probability (TCP) and Normal Tissue Complication Probability (NTCP) were performed and used for plan comparisons. Average minimum, mean, median and maximum tumor doses were 19.93, 27.83, 27.38, 39.60 Gy for GK and 20.17, 20.60, 20.59, 20.90 Gy for TOMO. Average gEUD values for tumor and normal brain were 25.0 and 7.2 Gy for GK and 20.7 and 8.1 Gy for TOMO. Conformity indices (CI) were similar for both modalities. Gradient indices (GI) were greater for TOMO. A combination plan was also generated using all eight tumors. TOMO was able to target all eight tumors simultaneously resulting in mean tumor and brain doses of 20.5 and 9.35 Gy, respectively. Due to the maximum limit of 50 beams per plan, GK was unable to provide a treatment plan for all eight tumors. GK provides an advantage for all tumor sizes with respect to tumor and normal brain dose. Clinical studies are needed to correlate these dosimetric findings with patient outcomes.
目的是比较螺旋断层放疗(TOMO)和伽玛刀(GK)治疗单发性和多发性脑肿瘤的剂量学。使用人体 Rando 头部模型来比较 TOMO 和 GK 的剂量学。使用 8 个不同形状、大小和位置的脑肿瘤生成 10 个计划。TOMO 计划的处方剂量为 20 Gy ,达到 100%等剂量线,GK 计划的处方剂量为 50%,达到 50%等剂量线。比较了肿瘤和脑的剂量体积直方图。进行了等效均匀剂量(gEUD)、肿瘤控制概率(TCP)和正常组织并发症概率(NTCP),并用于计划比较。GK 的平均最小、平均、中位数和最大肿瘤剂量分别为 19.93、27.83、27.38、39.60 Gy,TOMO 的平均最小、平均、中位数和最大肿瘤剂量分别为 20.17、20.60、20.59、20.90 Gy。GK 的平均 gEUD 值为肿瘤和正常脑分别为 25.0 和 7.2 Gy,TOMO 的平均 gEUD 值为肿瘤和正常脑分别为 20.7 和 8.1 Gy。两种模式的适形指数(CI)相似。TOMO 的梯度指数(GI)更大。还使用所有 8 个肿瘤生成了一个组合计划。TOMO 能够同时针对所有 8 个肿瘤,导致平均肿瘤和脑剂量分别为 20.5 和 9.35 Gy。由于每个计划最多允许 50 束,GK 无法为所有 8 个肿瘤提供治疗计划。GK 具有所有肿瘤大小的优势,在肿瘤和正常脑剂量方面。需要进行临床研究,将这些剂量学发现与患者结果相关联。
