Department of Radiation Oncology, Kinki University Faculty of Medicine, Osaka-Sayama, Japan.
J Radiat Res. 2013 Nov 1;54(6):1078-84. doi: 10.1093/jrr/rrt033. Epub 2013 Apr 14.
To visualize intratumoral hypoxic areas and their reoxygenation before and during fractionated radiation therapy (RT), (18)F-fluoromisonidazole positron emission tomography and computed tomography (F-MISO PET/CT) were performed. A total of 10 patients, consisting of four with head and neck cancers, four with gastrointestinal cancers, one with lung cancer, and one with uterine cancer, were included. F-MISO PET/CT was performed twice, before RT and during fractionated RT of approximately 20 Gy/10 fractions, for eight of the 10 patients. F-MISO maximum standardized uptake values (SUVmax) of normal muscles and tumors were measured. The tumor-to-muscle (T/M) ratios of F-MISO SUVmax were also calculated. Mean SUVmax ± standard deviation (SD) of normal muscles was 1.25 ± 0.17, and SUVmax above the mean + 2 SD (≥1.60 SUV) was regarded as a hypoxic area. Nine of the 10 tumors had an F-MISO SUVmax of ≥1.60. All eight tumors examined twice showed a decrease in the SUVmax, T/M ratio, or percentage of hypoxic volume (F-MISO ≥1.60) at approximately 20 Gy, indicating reoxygenation. In conclusion, accumulation of F-MISO of ≥1.60 SUV was regarded as an intratumoral hypoxic area in our F-MISO PET/CT system. Most human tumors (90%) in this small series had hypoxic areas before RT, although hypoxic volume was minimal (0.0-0.3%) for four of the 10 tumors. In addition, reoxygenation was observed in most tumors at two weeks of fractionated RT.
为了在分割放疗(RT)前后可视化肿瘤内缺氧区域及其再氧合,进行了(18)F-氟代米索硝唑正电子发射断层扫描和计算机断层扫描(F-MISO PET/CT)。共纳入 10 例患者,包括 4 例头颈部癌症、4 例胃肠道癌症、1 例肺癌和 1 例子宫癌患者。10 例患者中有 8 例在 RT 前和分割 RT 期间(约 20 Gy/10 个分次)进行了两次 F-MISO PET/CT。测量了正常肌肉和肿瘤的 F-MISO 最大标准化摄取值(SUVmax)。还计算了 F-MISO SUVmax 的肿瘤与肌肉(T/M)比值。正常肌肉的平均 SUVmax±标准差(SD)为 1.25±0.17,SUVmax 高于平均值+2 SD(≥1.60 SUV)被认为是缺氧区域。10 个肿瘤中有 9 个 F-MISO SUVmax≥1.60。两次检查的 8 个肿瘤均显示在大约 20 Gy 时 SUVmax、T/M 比值或缺氧体积百分比(F-MISO≥1.60)下降,表明再氧合。总之,我们的 F-MISO PET/CT 系统中,SUVmax≥1.60 的 F-MISO 累积被认为是肿瘤内的缺氧区域。在这个小系列中,大多数人类肿瘤(90%)在 RT 前存在缺氧区域,尽管其中 4 个肿瘤的缺氧体积最小(0.0-0.3%)。此外,在分割 RT 的两周时,大多数肿瘤都观察到了再氧合。
