(2,2'-联吡啶-κ(2) N,N')四-(二甲亚砜-κO)铜(II)双(高氯酸盐)

(2,2'-Bi-pyridine-κ(2) N,N')tetra-kis-(dimethyl sulfoxide-κO)copper(II) bis-(perchlorate).

作者信息

Iskenderov Turganbay

机构信息

Department of Chemistry, National Taras, Shevchenko University, Volodymyrska, Str. 64, 01601 Kyiv, Ukraine.

出版信息

Acta Crystallogr Sect E Struct Rep Online. 2013 Jul 10;69(Pt 8):m448-9. doi: 10.1107/S1600536813018485. eCollection 2013.

Abstract

The title compound, Cu(C2H6OS)4(C10H8N2)2, contains a Cu(II) ion with a distorted octa-hedral coordination environment, bonded by four O atoms of the monodentate dimethyl sulfoxide ligands and two N atoms of the bidentate chelating 2,2'-bi-pyridine ligand. The equatorial Cu-N and Cu-O bond lengths are in the range 1.979 (2)-1.998 (3) Å. The axial Cu-O bond distances are 2.365 (2) and 2.394 (2) Å. In the crystal, the complex cations and perchlorate anions are connected by numerous C-H⋯O hydrogen bonds, which leads to additional stabilization of the structure. The perchlorate anion is disordered over two sets of sites with a 0.716 (3):0.284 (3) occupancy ratio.

摘要

标题化合物Cu(C₂H₆OS)₄(C₁₀H₈N₂)₂包含一个具有扭曲八面体配位环境的Cu(II)离子,它通过四个单齿二甲基亚砜配体的O原子和两个双齿螯合2,2'-联吡啶配体的N原子键合。赤道平面上的Cu-N和Cu-O键长在1.979(2) - 1.998(3) Å范围内。轴向的Cu-O键距为2.365(2)和2.394(2) Å。在晶体中,配合物阳离子和高氯酸根阴离子通过大量的C-H⋯O氢键相连,这导致结构得到额外的稳定。高氯酸根阴离子在两组位置上无序分布,占有率比为0.716(3):0.284(3)。

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/251e/3793687/ffbb841ddb5c/e-69-0m448-fig1.jpg
