Fedorov Andriy, Penzkofer Tobias, Hirsch Michelle S, Flood Trevor A, Vangel Mark G, Masry Paul, Tempany Clare M, Mulkern Robert V, Fennessy Fiona M
Department of Radiology, Brigham and Women's Hospital, 75 Francis Street, Boston, MA 02115.
Department of Radiology, Brigham and Women's Hospital, 75 Francis Street, Boston, MA 02115; Department of Radiology, RWTH Aachen University Hospital, Aachen, Germany.
Acad Radiol. 2015 May;22(5):548-55. doi: 10.1016/j.acra.2014.12.022. Epub 2015 Feb 13.
Development of imaging biomarkers often relies on their correlation with histopathology. Our aim was to compare two approaches for correlating pathology to multiparametric magnetic resonance (MR) imaging (mpMRI) for localization and quantitative assessment of prostate cancer (PCa) index tumor using whole mount (WM) pathology (WMP) as the reference.
Patients (N = 30) underwent mpMRI that included diffusion-weighted imaging and dynamic contrast-enhanced (DCE) MRI at 3 T before radical prostatectomy (RP). RP specimens were processed using WM technique (WMP) and findings summarized in a standard surgical pathology report (SPR). Histology index tumor volumes (HTVs) were compared to MR tumor volumes (MRTVs) using two approaches for index lesion identification on mpMRI using annotated WMP slides as the reference (WMP) and using routine SPR as the reference. Consistency of index tumor localization, tumor volume, and mean values of the derived quantitative parameters (mean apparent diffusion coefficient [ADC], K(trans), and ve) were compared.
Index lesions from 16 of 30 patients met the selection criteria. There was WMP/SRP agreement in index tumor in 13 of 16 patients. ADC-based MRTVs were larger (P < .05) than DCE-based MRTVs. ADC MRTVs were smaller than HTV (P < .005). There was a strong correlation between HTV and MRTV (Pearson ρ > 0.8; P < .05). No significant differences were observed in the mean values of K(trans) and ADC between the WMP and SPR.
WMP correlation is superior to SPR for accurate localization of all index lesions. The use of WMP is however not required to distinguish significant differences of mean values of quantitative MRI parameters within tumor volume.
成像生物标志物的开发通常依赖于它们与组织病理学的相关性。我们的目的是比较两种将病理学与多参数磁共振(MR)成像(mpMRI)相关联的方法,以使用全层(WM)病理学(WMP)作为参考,对前列腺癌(PCa)指数肿瘤进行定位和定量评估。
30例患者在根治性前列腺切除术(RP)前接受了3T的mpMRI检查,包括扩散加权成像和动态对比增强(DCE)MRI。RP标本采用WM技术(WMP)处理,结果汇总在标准手术病理报告(SPR)中。使用两种方法在mpMRI上识别指数病变,将组织学指数肿瘤体积(HTV)与MR肿瘤体积(MRTV)进行比较,一种是以注释的WMP切片作为参考(WMP),另一种是以常规SPR作为参考。比较指数肿瘤定位、肿瘤体积以及导出的定量参数(平均表观扩散系数[ADC]、Ktrans和ve)平均值的一致性。
30例患者中有16例的指数病变符合选择标准。16例患者中有13例的指数肿瘤存在WMP/SRP一致性。基于ADC的MRTV比基于DCE的MRTV大(P <.05)。ADC MRTV小于HTV(P <.005)。HTV与MRTV之间存在强相关性(Pearson ρ> 0.8;P <.05)。WMP和SPR之间在Ktrans和ADC的平均值上未观察到显著差异。
WMP相关性在准确识别所有指数病变方面优于SPR。然而,在区分肿瘤体积内定量MRI参数平均值的显著差异时,并不需要使用WMP。
