Chan Hung-Pin, Hu Chin, Yu Chang-Ching, Huang Tsung-Chi, Peng Nan-Jing
From the Department of Nuclear Medicine (H-PC, CH, C-CY, T-CH, N-JP), Kaohsiung Veterans General Hospital; Department of Information Engineering (C-CY), I-Shou University, Kaohsiung; and National Yang-Ming University (N-JP), School of Medicine, Taipei, Taiwan.
Medicine (Baltimore). 2015 Apr;94(13):e687. doi: 10.1097/MD.0000000000000687.
Current nuclear imaging of the skeletal system is achieved using technetium-99m (Tc-99m) methylene diphosphonate (MDP), F-18 sodium fluoride (NaF), or F-18 fluorodeoxyglucose (FDG). However, comparisons of these are rare in the literature. We present a case of a 51-year-old female with suspicious lung cancer due to main symptoms of dyspnea, nonproductive cough, and pleural pain. Tc-99m MDP whole-body bone scan (WBBS) showed multiple bony metastases. Five days later, positron emission tomography/computed tomography (PET/CT) images using both F-18 NaF and a cocktail of F-18 NaF and F-18 FDG were obtained on the same day 2 hours apart. The former showed more foci and precisely showed bony lesions compared to those obtained using Tc-99m MDP WBBS. However, the latter demonstrated more extensive radiotracer uptake, especially in osteolytic lesions, and additional soft tissue lesions in the left axillary and surpraclavicular nodes as well as the left pleura. Surgical biopsy was performed in left axillary nodes, and the metastatic carcinoma was found to be of breast origin. This case demonstrated that a cocktail of F-18 NaF and F-18 FDG could be useful in PET/CT for not only detecting more skeletal lesions but also guiding biopsies accurately to the affected tissue.
目前,骨骼系统的核成像采用锝-99m(Tc-99m)亚甲基二膦酸盐(MDP)、F-18氟化钠(NaF)或F-18氟脱氧葡萄糖(FDG)来实现。然而,文献中对这些方法的比较很少。我们报告一例51岁女性,因呼吸困难、干咳和胸痛等主要症状怀疑患有肺癌。Tc-99m MDP全身骨扫描(WBBS)显示多处骨转移。五天后,同一天相隔2小时分别获得了使用F-18 NaF以及F-18 NaF与F-18 FDG混合剂的正电子发射断层扫描/计算机断层扫描(PET/CT)图像。与使用Tc-99m MDP WBBS获得的图像相比,前者显示出更多病灶,并能精确显示骨病变。然而,后者显示出更广泛的放射性示踪剂摄取,尤其是在溶骨性病变中,以及左腋窝和锁骨上淋巴结以及左胸膜处的额外软组织病变。对左腋窝淋巴结进行了手术活检,发现转移癌起源于乳腺。该病例表明,F-18 NaF与F-18 FDG的混合剂在PET/CT中不仅有助于检测更多的骨骼病变,还能准确地引导对受影响组织进行活检。
