Kim Daesik, Kim Sojung, Kim Sunghyun, Park Jeongbin, Kim Jin-Soo
Center for Genome Engineering, Institute for Basic Science, Seoul 151-747, South Korea; Department of Chemistry, Seoul National University, Seoul 151-747, South Korea;
Center for Genome Engineering, Institute for Basic Science, Seoul 151-747, South Korea;
Genome Res. 2016 Mar;26(3):406-15. doi: 10.1101/gr.199588.115. Epub 2016 Jan 19.
We present multiplex Digenome-seq to profile genome-wide specificities of up to 11 CRISPR-Cas9 nucleases simultaneously, saving time and reducing cost. Cell-free human genomic DNA was digested using multiple sgRNAs combined with the Cas9 protein and then subjected to whole-genome sequencing. In vitro cleavage patterns, characteristic of on- and off-target sites, were computationally identified across the genome using a new DNA cleavage scoring system. We found that many false-positive, bulge-type off-target sites were cleaved by sgRNAs transcribed from an oligonucleotide duplex but not by those transcribed from a plasmid template. Multiplex Digenome-seq captured many bona fide off-target sites, missed by other genome-wide methods, at which indels were induced at frequencies <0.1%. After analyzing 964 sites cleaved in vitro by these sgRNAs and measuring indel frequencies at hundreds of off-target sites in cells, we propose a guideline for the choice of target sites for minimizing CRISPR-Cas9 off-target effects in the human genome.
我们展示了多重双基因组测序技术,可同时分析多达11种CRISPR-Cas9核酸酶的全基因组特异性,节省时间并降低成本。使用与Cas9蛋白结合的多个sgRNA对无细胞的人类基因组DNA进行消化,然后进行全基因组测序。使用新的DNA切割评分系统,通过计算在全基因组中识别出体外切割模式,这些模式是靶向和脱靶位点的特征。我们发现,许多假阳性的凸起型脱靶位点被从寡核苷酸双链体转录的sgRNA切割,但未被从质粒模板转录的sgRNA切割。多重双基因组测序捕获了许多其他全基因组方法遗漏的真正脱靶位点,在这些位点上,插入缺失的诱导频率<0.1%。在分析了这些sgRNA在体外切割的964个位点并测量了细胞中数百个脱靶位点的插入缺失频率后,我们提出了在人类基因组中选择靶位点以最小化CRISPR-Cas9脱靶效应的指导原则。
