通过交流场调制磁力显微镜对单个纳米颗粒的磁行为进行定量探测。

Quantitatively probing the magnetic behavior of individual nanoparticles by an AC field-modulated magnetic force microscopy.

作者信息

Li Xiang, Lu Wei, Song Yiming, Wang Yuxin, Chen Aiying, Yan Biao, Yoshimura Satoru, Saito Hitoshi

机构信息

School of Materials Science and Engineering, University of Shanghai for Science and Technology, Shanghai 200093, China.

School of Materials Science and Engineering, Tongji University, Shanghai 201804, China.

出版信息

Sci Rep. 2016 Mar 2;6:22467. doi: 10.1038/srep22467.

Abstract

Despite decades of advances in magnetic imaging, obtaining direct, quantitative information with nanometer scale spatial resolution remains an outstanding challenge. Current approaches, for example, Hall micromagnetometer and nitrogen-vacancy magnetometer, are limited by highly complex experimental apparatus and a dedicated sample preparation process. Here we present a new AC field-modulated magnetic force microscopy (MFM) and report the local and quantitative measurements of the magnetic information of individual magnetic nanoparticles (MNPs), which is one of the most iconic objects of nanomagnetism. This technique provides simultaneously a direct visualization of the magnetization process of the individual MNPs, with spatial resolution and magnetic sensitivity of about 4.8 nm and 1.85 × 10(-20) A m(2), respectively, enabling us to separately estimate the distributions of the dipolar fields and the local switching fields of individual MNPs. Moreover, we demonstrate that quantitative magnetization moment of individual MNPs can be routinely obtained using MFM signals. Therefore, it underscores the power of the AC field-modulated MFM for biological and biomedical applications of MNPs and opens up the possibility for directly and quantitatively probing the weak magnetic stray fields from nanoscale magnetic systems with superior spatial resolution.

摘要

尽管磁成像技术在过去几十年取得了长足进展,但要获得具有纳米级空间分辨率的直接定量信息仍然是一项艰巨的挑战。例如,目前的方法,如霍尔微磁强计和氮空位磁强计,受到高度复杂的实验设备和专门的样品制备过程的限制。在此,我们展示了一种新型的交流场调制磁力显微镜(MFM),并报告了对单个磁性纳米颗粒(MNP)磁信息的局部和定量测量,MNP是纳米磁学中最具代表性的对象之一。该技术同时提供了单个MNP磁化过程的直接可视化,其空间分辨率和磁灵敏度分别约为4.8纳米和1.85×10^(-20) 安·米^2,使我们能够分别估计单个MNP的偶极场分布和局部开关场。此外,我们证明了使用MFM信号可以常规获得单个MNP的定量磁矩。因此,这突出了交流场调制MFM在MNP生物和生物医学应用中的强大功能,并为以卓越的空间分辨率直接和定量探测纳米级磁系统的弱磁杂散场开辟了可能性。

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/de59/4773816/94f89c77e7b0/srep22467-f1.jpg
