In this report, vertically free-standing lead zirconate titanate Pb(Zr0.52Ti0.48)O3 (PZT) nanocup arrays with good ordering and high density (1.3 × 10(10) cm(-2)) were demonstrated. By a template-assisted ion beam etching (IBE) strategy, the PZT formed in the pore-through anodic aluminum oxide (AAO) membrane on the Pt/Si substrate was with a cup-like nanostructure. The mean diameter and height of the PZT nanocups (NCs) was about 80 and 100 nm, respectively, and the wall thickness of NCs was about 20 nm with a hole depth of about 80 nm. Uppermost, the nanocup structure with low aspect ratio realized vertically free-standing arrays when losing the mechanical support from templates, avoiding the collapse or bundling when compared to the typical nanotube arrays. X-ray diffraction (XRD) and Raman spectrum revealed that the as-prepared PZT NCs were in a perovskite phase. By the vertical piezoresponse force microscopy (VPFM) measurements, the vertically free-standing ordered ferroelectric PZT NCs showed well-defined ring-like piezoresponse phase and hysteresis loops, which indicated that the high-density PZT nanocup arrays could have potential applications in ultra-high non-volatile ferroelectric memories (NV-FRAM) or other nanoelectronic devices.
在本报告中，展示了具有良好有序性和高密度（1.3×10¹⁰ cm⁻²）的垂直自支撑锆钛酸铅Pb(Zr₀.₅₂Ti₀.₄₈)O₃（PZT）纳米杯阵列。通过模板辅助离子束蚀刻（IBE）策略，在Pt/Si衬底上的通孔阳极氧化铝（AAO）膜中形成的PZT具有杯状纳米结构。PZT纳米杯（NCs）的平均直径和高度分别约为80和100 nm，NCs的壁厚约为20 nm，孔深约为80 nm。最重要的是，当失去模板的机械支撑时，具有低纵横比的纳米杯结构实现了垂直自支撑阵列，与典型的纳米管阵列相比，避免了坍塌或捆绑。X射线衍射（XRD）和拉曼光谱表明，所制备的PZT NCs为钙钛矿相。通过垂直压电响应力显微镜（VPFM）测量，垂直自支撑有序铁电PZT NCs显示出明确的环状压电响应相位和滞后回线，这表明高密度PZT纳米杯阵列在超高非易失性铁电存储器（NV-FRAM）或其他纳米电子器件中可能具有潜在应用。
