Dieleman Nikki, Yang Wenjie, Abrigo Jill M, Chu Winnie Chiu Wing, van der Kolk Anja G, Siero Jeroen C W, Wong Ka Sing, Hendrikse Jeroen, Chen Xiang Yan
From the Department of Radiology, University Medical Center Utrecht, The Netherlands (N.D., A.G.v.d.K., J.C.W.S., J.H.); and Department of Medicine (W.Y., K.S.W., X.Y.C.) and Department of Imaging and Interventional Radiology (J.M.A., W.C.W.C.), Chinese University of Hong Kong, Shatin, Hong Kong SAR, China.
Stroke. 2016 Jul;47(7):1797-802. doi: 10.1161/STROKEAHA.116.013007. Epub 2016 Jun 14.
Intracranial atherosclerosis is a major cause of ischemic stroke worldwide. Intracranial vessel wall imaging is an upcoming field of interest to assess intracranial atherosclerosis. In this study, we investigated total intracranial plaque burden in patients with symptomatic middle cerebral artery stenosis, assessed plaque morphological features, and compared features of symptomatic and asymptomatic lesions using a 3T vessel wall sequence.
Nineteen consecutive Chinese patients with ischemic stroke and transient ischemic attack (mean age: 67 years; 7 females) with a middle cerebral artery stenosis were scanned at 3T magnetic resonance imaging; the protocol included a time-of-flight magnetic resonance angiography and the T1-weighted volumetric isotropically reconstructed turbo spin echo acquisition sequence before and after (83%) contrast administration. Chi-square tests were used to assess associations between different plaque features. Statistical significance was set at P<0.05.
Vessel wall lesions were identified in 18 patients (95%), totaling 57 lesions in 494 segments (12% of segments). Lesions were located primarily in the anterior circulation (82%). Eccentric lesions were associated with a focal thickening pattern and concentric lesions with a diffuse thickening pattern (P<0.001). When differentiating between asymptomatic and symptomatic lesions, an association (P<0.05) was found between eccentricity and asymptomatic lesions, but not for enhancement or a specific thickening pattern. Symptomatic lesions did not have any specific morphological features.
Our results lead to a 2-fold conclusion: (1) The classification system of both thickening pattern and distribution of the lesion can be simplified by using distribution pattern only and (2) differentiation between symptomatic and asymptomatic atherosclerotic lesions was possible using intracranial vessel wall imaging.
颅内动脉粥样硬化是全球缺血性卒中的主要病因。颅内血管壁成像作为评估颅内动脉粥样硬化的一个新兴领域备受关注。在本研究中,我们使用3T血管壁序列,调查了有症状大脑中动脉狭窄患者的颅内斑块总负荷,评估了斑块形态特征,并比较了有症状和无症状病变的特征。
对19例连续的患有缺血性卒中和短暂性脑缺血发作(平均年龄:67岁;7名女性)且大脑中动脉狭窄的中国患者进行3T磁共振成像扫描;扫描方案包括时间飞跃磁共振血管造影以及在注射(83%)造影剂前后的T1加权容积各向同性重建快速自旋回波采集序列。采用卡方检验评估不同斑块特征之间的关联。设定P<0.05为具有统计学意义。
18例患者(95%)发现血管壁病变,494个节段中共发现57个病变(占节段的12%)。病变主要位于前循环(82%)。偏心性病变与局灶性增厚模式相关,同心性病变与弥漫性增厚模式相关(P<0.001)。在区分无症状和有症状病变时,发现偏心性与无症状病变之间存在关联(P<0.05),但增强或特定增厚模式与无症状病变之间无关联。有症状病变没有任何特定的形态特征。
我们的结果得出两点结论:(1)仅使用分布模式可简化病变增厚模式和分布的分类系统;(2)使用颅内血管壁成像可以区分有症状和无症状的动脉粥样硬化病变。
