Cheng Hao-Wen, Lo Wei-Lun, Kuo Chun-Yuan, Su Yu-Kai, Tsai Jo-Ting, Lin Jia-Wei, Wang Yu-Jen, Pan David Hung-Chi
Department of Radiation Oncology, Shuang Ho Hospital, Taipei Medical University, Taipei, Taiwan.
Gamma Knife Center, Shuang Ho Hospital, Taipei Medical University, Taipei, Taiwan.
J Appl Clin Med Phys. 2017 Nov;18(6):114-122. doi: 10.1002/acm2.12193. Epub 2017 Sep 27.
In Gamma Knife forward treatment planning, normalization effect may be observed when multiple shots are used for treating large lesions. This effect can reduce the proportion of coverage of high-value isodose lines within targets. The aim of this study was to evaluate the performance of forward treatment planning techniques using the Leksell Gamma Knife for the normalization effect reduction. We adjusted the shot positions and weightings to optimize the dose distribution and reduce the overlap of high-value isodose lines from each shot, thereby mitigating the normalization effect during treatment planning. The new collimation system, Leksell Gamma Knife Perfexion, which contains eight movable sectors, provides an additional means to reduce the normalization effect by using composite shots. We propose different techniques in forward treatment planning that can reduce the normalization effect. Reducing the normalization effect increases the coverage proportion of higher isodose lines within targets, making the high-dose region within targets more uniform and increasing the mean dose to targets. Because of the increase in the mean dose to the target after reducing the normalization effect, we can set the prescribed marginal dose at a higher isodose level and reduce the maximum dose, thereby lowering the risk of complications.
在伽玛刀正向治疗计划中,当使用多次照射治疗大病灶时,可能会观察到归一化效应。这种效应会降低靶区内高值等剂量线的覆盖比例。本研究的目的是评估使用Leksell伽玛刀的正向治疗计划技术在降低归一化效应方面的性能。我们调整照射位置和权重以优化剂量分布,并减少每次照射的高值等剂量线的重叠,从而在治疗计划期间减轻归一化效应。新的准直系统Leksell伽玛刀Perfexion包含八个可移动扇区,通过使用复合照射提供了另一种降低归一化效应的方法。我们提出了在正向治疗计划中可降低归一化效应的不同技术。降低归一化效应会增加靶区内较高等剂量线的覆盖比例,使靶区内的高剂量区域更均匀,并增加靶区的平均剂量。由于降低归一化效应后靶区平均剂量增加,我们可以将规定的边缘剂量设定在更高的等剂量水平,并降低最大剂量,从而降低并发症风险。
