College of Chemistry and Molecular Engineering, Qingdao University of Science & Technology, Qingdao 266042, China.
Research Center for Marine Ecology, The First Institute of Oceanography, State Oceanic Administration, Qingdao 266061, China.
Toxins (Basel). 2017 Sep 30;9(10):308. doi: 10.3390/toxins9100308.
Extracellular toxins released by marine toxigenic algae into the marine environment have attracted increasing attention in recent years. In this study, profiling, characterization and quantification of extracellular toxin compounds associated with diarrhetic shellfish poison (DSP) in the culture medium of toxin-producing dinoflagellates were performed using high-performance liquid chromatography-high-resolution mass spectrometry/tandem mass spectrometry for the first time. Results showed that solid-phase extraction can effectively enrich and clean the DSP compounds in the culture medium of (), and the proposed method achieved satisfactory recoveries (94.80%-100.58%) and repeatability (relative standard deviation ≤9.27%). Commercial software associated with the accurate mass information of known DSP toxins and their derivatives was used to screen and identify DSP compounds. Nine extracellular DSP compounds were identified, of which seven toxins (including OA-D7b, OA-D9b, OA-D10a/b, and so on) were found in the culture medium of for the first time. The results of quantitative analysis showed that the contents of extracellular DSP compounds in culture medium were relatively high, and the types and contents of intracellular and extracellular toxins apparently varied in the different growth stages of . The concentrations of extracellular okadaic acid and dinophysistoxin-1 were within 19.9-34.0 and 15.2-27.9 μg/L, respectively. The total concentration of the DSP compounds was within the range of 57.70-79.63 μg/L. The results showed that the proposed method is an effective tool for profiling the extracellular DSP compounds in the culture medium of marine toxigenic algae.
近年来,海洋产毒藻类向海洋环境中释放的细胞外毒素引起了越来越多的关注。本研究首次采用高效液相色谱-高分辨质谱/串联质谱技术对产毒甲藻培养液中的腹泻性贝类毒素(DSP)相关细胞外毒素化合物进行了分析、鉴定和定量。结果表明,固相萃取可有效富集和净化培养液中的 DSP 化合物,所提出的方法回收率(94.80%-100.58%)和重复性(相对标准偏差≤9.27%)均令人满意。利用与已知 DSP 毒素及其衍生物精确质量信息相关的商业软件对 DSP 化合物进行筛选和鉴定,共鉴定出 9 种细胞外 DSP 化合物,其中 7 种毒素(包括 OA-D7b、OA-D9b、OA-D10a/b 等)为首次在 中发现。定量分析结果表明,培养液中细胞外 DSP 化合物含量相对较高,不同生长阶段 细胞内外毒素的种类和含量明显不同。细胞外 okadaic 酸和 dinophysistoxin-1 的浓度分别为 19.9-34.0 和 15.2-27.9μg/L,DSP 化合物的总浓度在 57.70-79.63μg/L 范围内。结果表明,该方法是分析海洋产毒藻类培养液中细胞外 DSP 化合物的有效工具。
