Chicca Francesca Del, Schwarz Andrea, Meier Dieter, Grest Paula, Liesegang Annette, Kircher Patrick R
Clinic of Diagnostic Imaging, Equine Department, University of Zurich, 8057 Zurich, Switzerland.
Graduate School for Cellular and Biomedical Sciences, University of Bern, 3012 Bern, Switzerland.
J Vet Sci. 2018 Jul 31;19(4):570-576. doi: 10.4142/jvs.2018.19.4.570.
The objective of the present study was to describe two non-invasive methods for fat quantification in normal canine liver by using magnetic resonance imaging (MRI) and spectroscopy. Eleven adult beagle dogs were anesthetized and underwent magnetic resonance examination of the cranial abdomen by performing morphologic, modified Dixon (mDixon) dual gradient echo sequence, and proton magnetic resonance spectroscopy (H MRS) imaging. In addition, ultrasonographic liver examination was performed, fine-needle liver aspirates and liver biopsies were obtained, and hepatic triglyceride content was assayed. Ultrasonographic, cytologic, and histologic examination results were unremarkable in all cases. The median hepatic fat fraction calculated was 2.1% (range, 1.3%-5.5%) using mDixon, 0.3% (range, 0.1%-1.0%) using H MRS, and 1.6% (range 1.0%-2.5%) based on triglyceride content. The hepatic fat fractions calculated using mDixon and H MRS imaging were highly correlated to that based on triglyceride content. A weak correlation between mDixon and H MRS imaging was detected. The results show that hepatic fat content can be estimated using non-invasive techniques (mDixon or H MRS) in healthy dogs. Further studies are warranted to evaluate the use of these techniques in dogs with varying hepatic fat content and different hepatic disorders.
本研究的目的是描述两种使用磁共振成像(MRI)和波谱学对正常犬肝脏脂肪进行定量分析的非侵入性方法。11只成年比格犬接受麻醉,通过形态学、改良狄克逊(mDixon)双梯度回波序列和质子磁共振波谱(H MRS)成像对颅腹部进行磁共振检查。此外,还进行了肝脏超声检查,获取了肝脏细针穿刺抽吸物和肝活检组织,并测定了肝脏甘油三酯含量。所有病例的超声、细胞学和组织学检查结果均无异常。使用mDixon计算的肝脏脂肪分数中位数为2.1%(范围1.3%-5.5%),使用H MRS计算的为0.3%(范围0.1%-1.0%),基于甘油三酯含量计算的为1.6%(范围1.0%-2.5%)。使用mDixon和H MRS成像计算的肝脏脂肪分数与基于甘油三酯含量计算的结果高度相关。检测到mDixon和H MRS成像之间存在弱相关性。结果表明,健康犬肝脏脂肪含量可通过非侵入性技术(mDixon或H MRS)进行估计。有必要进一步研究评估这些技术在肝脏脂肪含量不同和患有不同肝脏疾病的犬中的应用。
