Shi Xuhan, Liu Bo, Liu Shijie, Niu Shifeng, Liu Shuang, Liu Ran, Liu Bingbing
State Key Laboratory of Superhard Materials, Jilin University, Changchun, 130012, P.R. China.
School of Physics and Engineering, and Henan Key Laboratory of Photoelectric Energy Storage Materials and Applications, Henan University of Science and Technology, Luoyang, 471003, China.
Sci Rep. 2018 Sep 13;8(1):13758. doi: 10.1038/s41598-018-31973-7.
Polymeric nitrogen, as a potential high-energy-density material (HEDM), has attracted many theoretical calculations and predictions for its potential applications, such as energy storage, propellants and explosives. Searching for an effective method to stabilize polymeric nitrogen in ambient conditions of temperature and pressure has become a hot topic. Herein, we propose a new hybrid material where polymeric nitrogen layers are intercalated in a multilayer BN matrix forming a three-dimensional structure, by means of ab initio density functional theory. It is demonstrated polymeric nitrogen layers can be stable at ambient conditions and can release tremendous energy just above 500 K, more gentle and controllable. Further calculations reveal the new hybrid material exhibits a much smaller charge transfer than that of previous reports, which not only stabilizes polymeric nitrogen layer at ambient conditions, but also favours energy releasing at milder conditions. It is also very exciting that, the weight ratio of polymeric nitrogen in new material is up to 53.84%, approximately three times higher than previous one-dimensional hybrid materials. The energy density (5.4 KJ/g) also indicates it is a promising HEDMs candidate. Our findings provide a new insight into nitrogen-based HEDMs capture and storage.
作为一种潜在的高能量密度材料(HEDM),聚合氮因其在储能、推进剂和炸药等潜在应用方面吸引了众多理论计算和预测。寻找一种在常温常压环境下稳定聚合氮的有效方法已成为一个热门话题。在此,我们借助从头算密度泛函理论,提出了一种新型杂化材料,其中聚合氮层插层在多层BN基质中形成三维结构。结果表明,聚合氮层在常温常压下能够稳定存在,并且在略高于500 K的温度下能够释放巨大能量,释放过程更加平缓且可控。进一步的计算表明,这种新型杂化材料的电荷转移比以往报道的要小得多,这不仅在常温常压下稳定了聚合氮层,而且有利于在较温和条件下释放能量。同样令人兴奋的是,新材料中聚合氮的重量比高达53.84%,约为之前一维杂化材料的三倍。其能量密度(5.4 KJ/g)也表明它是一种很有前景的高能量密度材料候选物。我们的研究结果为氮基高能量密度材料的捕获和存储提供了新的见解。
