Almeida Guilherme, Ashton Olivia J, Goldoni Luca, Maggioni Daniela, Petralanda Urko, Mishra Nimai, Akkerman Quinten A, Infante Ivan, Snaith Henry J, Manna Liberato
Clarendon Laboratory, Department of Physics , University of Oxford , Parks Road , OX1 3PU , Oxford , U.K.
Dipartimento di Chimica , Università degli Studi di Milano , Via Golgi 19 , 20133 Milano , Italy.
J Am Chem Soc. 2018 Nov 7;140(44):14878-14886. doi: 10.1021/jacs.8b08978. Epub 2018 Oct 25.
We report an amine-free synthesis of lead halide perovskite (LHP) nanocrystals, using trioctylphosphine oxide (TOPO) instead of aliphatic amines, in combination with a protic acid (e.g., oleic acid). The overall synthesis scheme bears many similarities to the chemistry behind the preparation of LHP thin films and single crystals, in terms of ligand coordination to the chemical precursors. The acidity of the environment and hence the extent of protonation of the TOPO molecules tune the reactivity of the PbX precursor, regulating the size of the nanocrystals. On the other hand, TOPO molecules are virtually absent from the surface of our nanocrystals, which are simply passivated by one type of ligand (e.g., Cs-oleate). Furthermore, our studies reveal that Cs-oleate is dynamically bound to the surface of the nanocrystals and that an optimal surface coverage is critical for achieving high photoluminescence quantum yield. Our scheme delivers NCs with a controlled size and shape: only cubes are formed, with no contamination with platelets, regardless of the reaction conditions that were tested. We attribute such a shape homogeneity to the absence of primary aliphatic amines in our reaction environment, since these are known to promote the formation of nanocrystals with sheet/platelet morphologies or layered phases under certain reaction conditions. The TOPO route is particularly appealing with regard to synthesizing LHP nanocrystals for large-scale manufacturing, as the yield in terms of material produced is close to the theoretical limit: i.e., almost all precursors employed in the synthesis are converted into nanocrystals.
我们报道了一种无胺合成卤化铅钙钛矿(LHP)纳米晶体的方法,该方法使用三辛基氧化膦(TOPO)代替脂肪族胺,并与质子酸(如油酸)结合使用。就配体与化学前体的配位而言,整个合成方案与LHP薄膜和单晶制备背后的化学过程有许多相似之处。环境的酸度以及因此TOPO分子的质子化程度调节了PbX前体的反应性,从而调节了纳米晶体的尺寸。另一方面,我们的纳米晶体表面几乎不存在TOPO分子,其仅被一种类型的配体(如油酸铯)钝化。此外,我们的研究表明,油酸铯动态地结合在纳米晶体表面,并且最佳的表面覆盖率对于实现高光致发光量子产率至关重要。我们的方案提供了尺寸和形状可控的纳米晶体:无论测试何种反应条件,只形成立方体,无片状物污染。我们将这种形状均匀性归因于反应环境中不存在伯脂肪族胺,因为已知在某些反应条件下,这些胺会促进形成具有片状/板状形态或层状相的纳米晶体。就大规模制造而言,TOPO路线对于合成LHP纳米晶体特别有吸引力,因为就所生产的材料而言,产率接近理论极限:即合成中使用的几乎所有前体都转化为纳米晶体。
