Department of Clinic and Veterinary Surgery, São Paulo State University (Unesp), School of Agricultural and Veterinarian Sciences, Jaboticabal, Jaboticabal, Sao Paulo, Brazil.
Institute of Agrarian Sciences, Federal University of the Jequitinhonha and Mucuri Valleys (UFVJM), Unaí, Minas Gerais, Brazil.
Sci Rep. 2018 Dec 7;8(1):17708. doi: 10.1038/s41598-018-34806-9.
The aim of this study was to evaluate and compare the diagnostic accuracy of B-mode, Doppler ultrasonography and Acoustic Radiation Force Impulse (ARFI) elastography in the identification of axillary and inguinal lymph nodes metastasis in bitches with mammary neoplasms. The axillary (n = 96) and inguinal (n = 100) lymph nodes of 100 bitches were evaluated using B-Mode, Colour Doppler and ARFI-elastography. After this evaluation, mastectomy and lymph nodes excision were performed and these structures were histologically classified as free, reactive or metastatic. Ultrasonographic parameters were compared by Chi-Square or ANOVA tests and if they are significant, discriminative power analysis according to histopathological classification was performed (ROC analysis). The ARFI-elastography shear wave velocity (SWV) enabled metastasis identification in inguinal (sensitivity 95% specificity 87%) and axillary lymph nodes (sensitivity 100% specificity 94%). While B-Mode ultrasound Short/Long axis ratio evaluation of inguinal and axillary lymph nodes only resulted in a sensitivity around of 71% and specificity of 55%. In conclusion, B-Mode ultrasonography may contribute to diagnosis of metastasis in axillary and inguinal lymph nodes of bitches affected by mammary neoplasm with limited accuracy, while SWV evaluation proved to be an excellent diagnosis tool, which allows differentiation between free, reactive and tumour metastatic lymph nodes.
本研究旨在评估和比较 B 模式、多普勒超声和声辐射力脉冲(ARFI)弹性成像在鉴别患有乳腺肿瘤的母犬腋窝和腹股沟淋巴结转移方面的诊断准确性。使用 B 模式、彩色多普勒和 ARFI 弹性成像对 100 只母犬的腋窝(n=96)和腹股沟(n=100)淋巴结进行评估。评估后,对这些母犬进行了乳房切除术和淋巴结切除术,并对这些结构进行了组织学分类,分为游离、反应性或转移性。采用卡方检验或方差分析比较超声参数,如果有统计学意义,则根据组织病理学分类进行判别能力分析(ROC 分析)。ARFI 弹性成像的剪切波速度(SWV)能够识别腹股沟(敏感性 95%,特异性 87%)和腋窝淋巴结(敏感性 100%,特异性 94%)的转移。而 B 模式超声对腹股沟和腋窝淋巴结的短/长轴比评估仅导致敏感性约为 71%,特异性为 55%。总之,B 模式超声检查可能有助于诊断患有乳腺肿瘤的母犬的腋窝和腹股沟淋巴结转移,但准确性有限,而 SWV 评估被证明是一种出色的诊断工具,可区分游离、反应性和肿瘤转移性淋巴结。
