Saha Anubha, Roy Sanchita
Department of Anatomy, Calcutta National Medical College, West Bengal, India.
Department of Anatomy, Institute of Post Graduation Medical Education & Research, 244, A.J.C Bose Road, Kolkata-700020, West Bengal, India.
Indian Heart J. 2018 Nov-Dec;70(6):894-900. doi: 10.1016/j.ihj.2017.12.003. Epub 2017 Dec 11.
The two left ventricular papillary muscles are small structures at sternocostal and inferior wall but are vital to mitral valve competence. Extra papillary muscles could be found. Partial or complete rupture, complicating acute myocardial infarction, causes severe or even catastrophic mitral regurgitation, potentially correctable by surgery. Detailed knowledge of normal anatomy and variations is vital for accurate interpretation of information by echocardiography and for surgical repair.
The material for present study consisted of 52 formalin fixed adult apparently normal cadaveric hearts belonging to either sex obtained from the Department of Anatomy. These hearts were dissected carefully to open the left ventricle and to expose the papillary muscles. According to their attitudinal position they were described as supero-lateral (S-L) and inferoseptal muscle (I-S) instead of conventional anterolateral and posteromedial. Different morphological features of papillary muscles were noted and measurements were taken.
Classical picture of left ventricular papillary muscle was found only in 25% cases. Additionally extra muscles were found 34.61% and 71.15% in S-L and I-S group, respectively. Different shapes and pattern of papillary muscles were also been identified. An additional attribute of this study was measurement of length and breadth of papillary muscles which thus provides a base line data for further detailed studies in a large scale.
Oriental nomenclature is necessary not only for anatomist but also for electrocardiographers. Breadth of papillay muscle should be taken into morphometric account as for screening of hypertrophic cardiomyopathy. Proper anatomical knowledge is crucial for clinicians, surgeons and radiologists.
左心室的两根乳头肌是位于胸骨旁和下壁的小结构,但对二尖瓣功能至关重要。可能会发现额外的乳头肌。急性心肌梗死并发的部分或完全断裂会导致严重甚至灾难性的二尖瓣反流,手术可能可纠正。对正常解剖结构及其变异的详细了解对于超声心动图信息的准确解读和手术修复至关重要。
本研究材料包括52颗来自解剖学系的经福尔马林固定的成年男女看似正常的尸体心脏。仔细解剖这些心脏以打开左心室并暴露乳头肌。根据其方位,将它们描述为上外侧(S-L)和下间隔肌(I-S),而非传统的前外侧和后内侧。记录乳头肌的不同形态特征并进行测量。
仅在25%的病例中发现左心室乳头肌的经典形态。此外,分别在S-L组和I-S组中发现34.61%和71.15%的额外肌肉。还识别出乳头肌的不同形状和模式。本研究的另一个特点是测量乳头肌的长度和宽度,从而为大规模进一步详细研究提供基线数据。
东方命名法不仅对解剖学家,而且对心电图学家都是必要的。在筛查肥厚型心肌病时,应将乳头肌宽度纳入形态测量考虑。正确的解剖学知识对临床医生、外科医生和放射科医生至关重要。
