Mokry Guillermo, Pozuelo Javier, Vilatela Juan J, Sanz Javier, Baselga Juan
Departamento de Ciencia e Ingeniería de Materiales e Ingeniería Química (IAAB), Universidad Carlos III de Madrid, 28911 Leganés, Madrid, Spain.
IMDEA Materials Institute, Eric Kandel 2, Getafe, 28906 Madrid, Spain.
Nanomaterials (Basel). 2019 Mar 6;9(3):383. doi: 10.3390/nano9030383.
Constant evolution of technology is leading to the improvement of electronical devices. Smaller, lighter, faster, are but a few of the properties that have been constantly improved, but these developments come hand in hand with negative downsides. In the case of miniaturization, this shortcoming is found in the inherent property of conducting materials-the limit of current density they can withstand before failure. This property, known as ampacity, is close to reaching its limits at the current scales of use, and the performances of some conductors such as gold or copper suffer severely from it. The need to find alternative conductors with higher ampacity is, therefore, an urgent need, but at the same time, one which requires simultaneous search for decreased density if it is to succeed in an ever-growing electronical world. The uses of these carbon nanotube-based materials, from airplane lightning strike protection systems to the microchip industry, will be evaluated, failure mechanisms at maximum current densities explained, limitations and difficulties in ampacity measurements with different size ranges evaluated, and future lines of research suggested. This review will therefore provide an in-depth view of the rare properties that make carbon nanotubes and their hybrids unique.
技术的不断发展促使电子设备得以改进。体积更小、重量更轻、速度更快,这些只是不断得到改善的部分特性,但这些发展也伴随着负面影响。就小型化而言,这一缺点体现在导电材料的固有特性上,即它们在失效前所能承受的电流密度极限。这种特性,即载流量,在当前的使用规模下已接近极限,一些导体(如金或铜)的性能因此受到严重影响。因此,迫切需要找到具有更高载流量的替代导体,但与此同时,如果要在不断发展的电子世界中取得成功,还需要同时寻求降低密度。本文将评估这些基于碳纳米管的材料在从飞机雷击保护系统到微芯片行业等领域的应用,解释最大电流密度下的失效机制,评估不同尺寸范围内载流量测量的局限性和困难,并提出未来的研究方向。因此,本综述将深入探讨使碳纳米管及其复合材料独一无二的罕见特性。
