Dieterich Marianne, Brandt Thomas
German Center for Vertigo and Balance Disorders, Ludwig-Maximilians University, Munich, Germany.
Department of Neurology, Ludwig-Maximilians University, Munich, Germany.
Front Neurol. 2019 Apr 3;10:172. doi: 10.3389/fneur.2019.00172. eCollection 2019.
To review current knowledge of the perception of verticality, its normal function and disorders. This is based on an integrative graviceptive input from the vertical semicircular canals and the otolith organs. The special focus is on human psychophysics, neurophysiological and imaging data on the adjustments of subjective visual vertical (SVV) and the subjective postural vertical. Furthermore, examples of mathematical modeling of specific vestibular cell functions for orientation in space in rodents and in patients are briefly presented. Pathological tilts of the SVV in the roll plane are most sensitive and frequent clinical vestibular signs of unilateral lesions extending from the labyrinths via the brainstem and thalamus to the parieto-insular vestibular cortex. Due to crossings of ascending graviceptive fibers, peripheral vestibular and pontomedullary lesions cause ipsilateral tilts of the SVV; ponto-mesencephalic lesions cause contralateral tilts. In contrast, SVV tilts, which are measured in unilateral vestibular lesions at thalamic and cortical levels, have two different characteristic features: (i) they may be ipsi- or contralateral, and (ii) they are smaller than those found in lower brainstem or peripheral lesions. Motor signs such as head tilt and body lateropulsion, components of ocular tilt reaction, are typical for vestibular lesions of the peripheral vestibular organ and the pontomedullary brainstem (vestibular nucleus). They are less frequent in midbrain lesions (interstitial nucleus of Cajal) and rare in cortical lesions. Isolated body lateropulsion is chiefly found in caudal lateral medullary brainstem lesions. Vestibular function in the roll plane and its disorders can be mathematically modeled by an attractor model of angular head velocity cell and head direction cell function. Disorders manifesting with misperception of the body vertical are the pusher syndrome, the progressive supranuclear palsy, or the normal pressure hydrocephalus; they may affect roll and/or pitch plane. Clinical determinations of the SVV are easy and reliable. They indicate acute unilateral vestibular dysfunctions, the causative lesion of which extends from labyrinth to cortex. They allow precise topographical diagnosis of side and level in unilateral brainstem or peripheral vestibular disorders. SVV tilts may coincide with or differ from the perception of body vertical, e.g., in isolated body lateropulsion.
回顾关于垂直感知、其正常功能及障碍的当前知识。这基于来自垂直半规管和耳石器官的整合重力感受性输入。特别关注人类心理物理学、神经生理学以及关于主观视觉垂直(SVV)和主观姿势垂直调整的成像数据。此外,简要介绍了啮齿动物和患者中用于空间定向的特定前庭细胞功能的数学建模示例。SVV在横滚平面的病理性倾斜是最敏感且常见的临床前庭体征,见于从迷路经脑干和丘脑延伸至顶叶 - 岛叶前庭皮层的单侧病变。由于上行重力感受纤维的交叉,外周前庭和脑桥延髓病变导致SVV同侧倾斜;脑桥中脑病变导致对侧倾斜。相比之下,在丘脑和皮层水平的单侧前庭病变中测量到的SVV倾斜具有两个不同的特征:(i)它们可能是同侧或对侧的,(ii)它们比在下脑干或外周病变中发现的倾斜小。诸如头部倾斜和身体侧推等运动体征,是眼倾斜反应的组成部分,是外周前庭器官和脑桥延髓脑干(前庭核)前庭病变的典型表现。它们在中脑病变(Cajal间质核)中较少见,在皮层病变中罕见。孤立的身体侧推主要见于延髓尾外侧脑干病变。横滚平面的前庭功能及其障碍可以通过角头速度细胞和头方向细胞功能的吸引子模型进行数学建模。表现为身体垂直感知错误的障碍有推者综合征、进行性核上性麻痹或正常压力脑积水;它们可能影响横滚和/或俯仰平面。SVV的临床测定简单可靠。它们可指示急性单侧前庭功能障碍,其病因性病变从迷路延伸至皮层。它们有助于对单侧脑干或外周前庭疾病的侧别和水平进行精确的定位诊断。SVV倾斜可能与身体垂直感知一致或不同,例如在孤立的身体侧推中。
