Sone Daichi, Maikusa Norihide, Sato Noriko, Kimura Yukio, Ota Miho, Matsuda Hiroshi
Integrative Brain Imaging Center, National Center of Neurology and Psychiatry, Tokyo, Japan.
Department of Radiology, National Center of Neurology and Psychiatry, Tokyo, Japan.
Front Neurol. 2019 Apr 3;10:318. doi: 10.3389/fneur.2019.00318. eCollection 2019.
Despite the increasing use of arterial spin labeling (ASL) in patients with epilepsy, little is known about its brain regional distribution pattern, including diaschisis, and its correspondence with FDG-PET. Here, we investigated the regional match and mismatch between FDG-PET and ASL in temporal lobe epilepsy (TLE). We recruited 27 patients with unilateral TLE, who underwent inter-ictal ASL and FDG-PET scans. These images were spatially normalized using Statistical Parametric Mapping 12, and the regional values in both ASL and FDG-PET were calculated using PMOD software within 20 volumes of interest (VOIs), including the temporal lobe, adjacent cortices, subcortical structures, and cerebellum. ASL images of 37 healthy controls were also analyzed and compared. Whereas, ASL showed significant side differences, mainly in the temporal and frontal lobes, the significant abnormalities in FDG-PET were more widespread and included the insula and supramarginal gyrus. Ipsilateral thalamic reduction was found in FDG-PET only. The detectability of the focus side compared with the contralateral side was generally higher in FDG-PET. The discriminative values in ASL compared with healthy controls were higher in temporal neocortex and amygdala VOIs. There are similar and differing regional distributions between FDG-PET and ASL in TLE, possibly reflecting regional match and mismatch of cerebral blood flow and metabolism. At this stage, it seems that ASL couldn't present comparable clinical usefulness with FDG-PET. These findings deepen our knowledge of ASL imaging and are potentially useful for its further application.
尽管动脉自旋标记(ASL)在癫痫患者中的应用日益增多,但对于其脑区分布模式,包括远隔性机能障碍,以及与氟代脱氧葡萄糖正电子发射断层扫描(FDG-PET)的对应关系,我们却知之甚少。在此,我们研究了颞叶癫痫(TLE)患者中FDG-PET与ASL之间的区域匹配和不匹配情况。我们招募了27例单侧TLE患者,他们接受了发作间期的ASL和FDG-PET扫描。这些图像使用统计参数映射12进行空间归一化处理,并使用PMOD软件在20个感兴趣区(VOI)内计算ASL和FDG-PET的区域值,这些感兴趣区包括颞叶、相邻皮质、皮质下结构和小脑。我们还分析并比较了37名健康对照者的ASL图像。尽管ASL显示出显著的双侧差异,主要在颞叶和额叶,但FDG-PET中的显著异常更为广泛,包括脑岛和缘上回。仅在FDG-PET中发现同侧丘脑减低。与对侧相比,FDG-PET中病灶侧的可检测性通常更高。与健康对照相比,ASL在颞叶新皮质和杏仁核VOI中的鉴别值更高。TLE患者中FDG-PET和ASL之间存在相似和不同的区域分布,这可能反映了脑血流和代谢的区域匹配和不匹配。在现阶段,ASL似乎无法呈现与FDG-PET相当的临床效用。这些发现加深了我们对ASL成像的认识,并可能对其进一步应用具有潜在的帮助。
