基于自适应非奇异快速终端滑模控制的三轴通用惯性稳定平台在低速跟踪和大角度摆动扫描方面的高性能。

High Performance Both in Low-Speed Tracking and Large-Angle Swing Scanning Based on Adaptive Nonsingular Fast Terminal Sliding Mode Control for a Three-Axis Universal Inertially Stabilized Platform.

作者信息

Wang Yuanchao, Yang Yongming, Kuang Haipeng, Yuan Dongming, Yu Chunfeng, Chen Juan, Hua Nan, Hou Han

机构信息

Changchun Institute of Optics, Fine Mechanics and Physics, Chinese Academy of Sciences, Changchun 130033, China.

Key Laboratory of Airborne Optical Imaging and Measurement, Chinese Academy of Sciences, Changchun 130033, China.

出版信息

Sensors (Basel). 2020 Oct 13;20(20):5785. doi: 10.3390/s20205785.

Abstract

In order to improve the performance in the practical engineering applications including so called low-speed video tracking and large-angle swing scanning imaging at the same time for a three-axis universal inertially stabilized platform (UISP), we propose an adaptive nonsingular fast terminal sliding mode control (ANFTSMC) strategy subjected to the uncertain disturbances and input saturation constraints. First of all, a second-order dynamic model is established with uncertain disturbances and input saturation constraints. Secondly, a nonsingular fast terminal sliding mode controller (NTSMC) is constructed to ensure the system error converges to zero fast in a finite time; meanwhile, a novel reaching law based on a modified normal distribution function is designed to adjust the control gain. Thirdly, an adaptive control law is designed to online estimate the parameters of the lumped uncertain disturbances. Additionally, the stability of the control system is proved by Lyapunov theory. Finally, extensive comparative simulations and experiments are carried out, the results comprehensively show the effectiveness and superiority of the proposed control method, which can accelerate convergence, weaken the chattering, and has the better control accuracy and robust performance both in the low-speed tracking and large-angle swing scanning applications. Moreover, the exact dynamic model and the prior knowledge of the upper bounds of the disturbances are not required during the procedure of the controller design, which make it have more extensive application value in practical engineering.

摘要

为了提高三轴通用惯性稳定平台(UISP)在实际工程应用中的性能,使其能够同时实现所谓的低速视频跟踪和大角度摆动扫描成像,我们提出了一种适用于不确定干扰和输入饱和约束的自适应非奇异快速终端滑模控制(ANFTSMC)策略。首先,建立了一个具有不确定干扰和输入饱和约束的二阶动态模型。其次,构建了一个非奇异快速终端滑模控制器(NTSMC),以确保系统误差在有限时间内快速收敛到零;同时,设计了一种基于修正正态分布函数的新型趋近律来调整控制增益。第三,设计了一种自适应控制律,用于在线估计集总不确定干扰的参数。此外,利用李雅普诺夫理论证明了控制系统的稳定性。最后,进行了广泛的对比仿真和实验,结果全面表明了所提出控制方法的有效性和优越性,该方法在低速跟踪和大角度摆动扫描应用中能够加速收敛、减弱抖振,并且具有更好的控制精度和鲁棒性能。此外,在控制器设计过程中不需要精确的动态模型和干扰上界的先验知识,这使得其在实际工程中具有更广泛的应用价值。
