用于生命体征的 IR-UWB 雷达与 FMCW 雷达的实验比较。

Experimental Comparison of IR-UWB Radar and FMCW Radar for Vital Signs.

机构信息

Department of Electronics and Computer Engineering, Hanyang University, Seoul 04763, Korea.

出版信息

Sensors (Basel). 2020 Nov 23;20(22):6695. doi: 10.3390/s20226695.


DOI:10.3390/s20226695
PMID:33238557
原文链接:https://pmc.ncbi.nlm.nih.gov/articles/PMC7768379/
Abstract

In this paper, we compare the performances of impulse radio ultra-wideband (IR-UWB) and frequency modulation continuous wave (FMCW) radars in measuring noncontact vital signs such as respiration rate and heart rate. These two type radars have been widely used in various fields and have shown their applicability to extract vital signs in noncontact ways. IR-UWB radar can extract vital signs using distance information. On the other hand, FMCW radar requires phase information to estimate vital signs, and the result can be enhanced with Multi-input Multi-output (MIMO) antenna topologies. By using commercial radar chipsets, the operation of radars under different conditions and frequency bands will also affect the performance of vital sign detection capabilities. We compared the accuracy and signal-to-noise (SNR) ratios of IR-UWB and FMCW radars in various scenarios, such as distance, orientation, carotid pulse, harmonics, and obstacle penetration. In general, the IR-UWB radars offer a slightly better accuracy and higher SNR in comparison to FMCW radar. However, each radar system has its own unique advantages, with IR-UWB exhibiting fewer harmonics and a higher SNR, while FMCW can combine the results from each channel.

摘要

在本文中,我们比较了脉冲无线电超宽带(IR-UWB)和调频连续波(FMCW)雷达在测量非接触生命体征(如呼吸率和心率)方面的性能。这两种类型的雷达已广泛应用于各个领域,并已证明它们适用于以非接触方式提取生命体征。IR-UWB 雷达可以使用距离信息提取生命体征。另一方面,FMCW 雷达需要相位信息来估计生命体征,并且可以通过多输入多输出(MIMO)天线拓扑结构来增强结果。通过使用商业雷达芯片组,雷达在不同条件和频带下的操作也会影响生命体征检测能力的性能。我们比较了在不同场景(例如距离、方向、颈动脉搏动、谐波和障碍物穿透)下,IR-UWB 和 FMCW 雷达的准确性和信噪比(SNR)。一般来说,与 FMCW 雷达相比,IR-UWB 雷达的准确性略高,信噪比更高。然而,每个雷达系统都有其独特的优势,IR-UWB 显示出较少的谐波和更高的 SNR,而 FMCW 可以组合每个通道的结果。
