Nonreciprocal elasticity and the realization of static and dynamic nonreciprocity.

The realization of the mechanical nonreciprocity requires breaking either the time-reversal symmetry or the material deformation symmetry. The time-reversal asymmetry was the commonly adopted approach to realize dynamic nonreciprocity. However, a static nonreciprocity requires-with no any other option-breaking the material deformation symmetry. By virtue of the Maxwell-Betti reciprocal theorem, the achievement of the static nonreciprocity seems to be conditional by the use of a nonlinear material. Here, we further investigate this and demonstrate a novel "nonreciprocal elasticity" concept. We investigated the conditions of the attainment of effective static nonreciprocity. We revealed that the realization of static nonreciprocity requires breaking the material deformation symmetry under the same kinematical and kinetical conditions, which can be achieved only and only if the material exhibits a nonreciprocal elasticity. By means of experimental and topological mechanics, we demonstrate that the realization of static nonreciprocity requires nonreciprocal elasticity no matter what the material is linear or nonlinear. We experimentally demonstrated linear and nonlinear metamaterials with nonreciprocal elasticities. The developed metamaterials were used to demonstrate that nonreciprocal elasticity is essential to realize static nonreciprocal-topological systems. The nonreciprocal elasticity developed here will open new venues of the design of metamaterials that can effectively break the material deformation symmetry and achieve, both, static and dynamic nonreciprocity.
