Capitano Dana, Hu Zhixiang, Liu Yu, Tong Xiao, Nykypanchuk Dmytro, DiMarzio Donald, Petrovic Cedomir
Condensed Matter Physics and Materials Science Department, Brookhaven National Laboratory, Upton, New York 11973, United States.
Department of Materials Science and Chemical Engineering, Stony Brook University, Stony Brook, New York 11790, United States.
ACS Omega. 2021 Apr 12;6(16):10537-10546. doi: 10.1021/acsomega.0c04872. eCollection 2021 Apr 27.
Ultrathin crystals including monolayers have been reported for various transition-metal dichalcogenides (TMDCs) with van der Waals bonds in the crystal structure. Herein, we report a detailed synthesis procedure and characterization of ultrathin iron ditelluride crystals. This material crystallizes in an orthorhombic marcasite crystal structure whose bonding is dominantly covalent and without loosely connected van der Waals (vdW) bonds, making monolayer FeTe synthesis less straightforward than other TMDC monolayer syntheses. The chemical vapor deposition synthesis process described is simple, effective, and results in a range of crystal thicknesses from approximately 400 nm down to the FeTe monolayer.
据报道,包括单层在内的超薄晶体已应用于各种晶体结构中具有范德华键的过渡金属二硫属化物(TMDC)。在此,我们报告了超薄碲化铁晶体的详细合成过程及表征。这种材料结晶为正交硫铁矿晶体结构,其键合主要是共价键,没有松散连接的范德华(vdW)键,这使得单层FeTe的合成比其他TMDC单层合成更复杂。所描述的化学气相沉积合成过程简单、有效,可得到一系列晶体厚度,从约400纳米到FeTe单层。
