Native T1 mapping and extracellular volume fraction for differentiation of myocardial diseases from normal CMR controls in routine clinical practice.

BACKGROUND

This study aimed to determine native T1 and extracellular volume fraction (ECV) in distinct types of myocardial disease, including amyloidosis, dilated cardiomyopathy (DCM), hypertrophic cardiomyopathy (HCM), myocarditis and coronary artery disease (CAD), compared to controls.

METHODS

We retrospectively enrolled patients with distinct types of myocardial disease, CAD patients, and control group (no known heart disease and negative CMR study) who underwent 3.0 Tesla CMR with routine T1 mapping. The region of interest (ROI) was drawn in the myocardium of the mid left ventricular (LV) short axis slice and at the interventricular septum of mid LV slice. ECV was calculated by actual hematocrit (Hct) and synthetic Hct. T1 mapping and ECV was compared between myocardial disease and controls, and between CAD and controls. Diagnostic yield and cut-off values were assessed.

RESULTS

A total of 1188 patients were enrolled. The average T1 values in the control group were 1304 ± 42 ms at septum, and 1294 ± 37 ms at mid LV slice. The average T1 values in patients with myocardial disease and CAD were significantly higher than in controls (1441 ± 72, 1349 ± 59, 1345 ± 59, 1355 ± 56, and 1328 ± 54 ms for septum of amyloidosis, DCM, HCM, myocarditis, and CAD). Native T1 of the mid LV level and ECV at septum and mid LV with actual and synthetic Hct of patients with myocardial disease or CAD were significantly higher than in controls.

CONCLUSIONS

Although native T1 and ECV of patients with cardiomyopathy and CAD were significantly higher than controls, the values overlapped. The greatest clinical utilization was found for the amyloidosis group.
