Sudjaipraparat Narissara, Suteewong Teeraporn, Tangboriboonrat Pramuan
Department of Chemistry, Faculty of Science, Mahidol University, Rama 6 Road, Phyathai, Bangkok 10400, Thailand.
Department of Chemical Engineering, School of Engineering, King Mongkut's Institute of Technology Ladkrabang, Ladkrabang, Bangkok 10520, Thailand.
Polymers (Basel). 2021 Jul 30;13(15):2526. doi: 10.3390/polym13152526.
Zinc oxide polymeric nanoparticles (ZPPs) of poly (styrene-co-acrylic acid) P(St/AA), containing oleic acid modified zinc oxide nanoparticles (OA-ZnO NPs), were synthesized via miniemulsion polymerization. By simply adjusting the quantity of reactants, i.e., sodium dodecyl sulfate (SDS) surfactant, potassium persulfate (KPS) initiator, and divinyl benzene (DVB) crosslinking agent, the location of ZnO NPs were altered from the inner (core) to the outer (shell), leading to core-shell and Pickering-like morphologies, respectively. The Pickering-like ZPPs were obtained when using SDS at below or equal to the critical micelle concentration (CMC). At above the CMC, the complete encapsulation of OA-ZnO NPs within the ZPPs depicted a kinetically controlled morphology. The transition to Pickering-like ZPPs also occurred when reducing the KPS from 2 to 0.5-1%. Whereas the DVB accelerated the polymerization rate and viscosity in the growing monomer-swollen nanodroplets and, hence, contributed to kinetic parameters on particle morphology, i.e., an increase in the DVB content increased the rate of polymerization. A hollow structure was obtained by replacing styrene with the more hydrophilic monomer, i.e., methyl methacrylate. All ZPPs-incorporated poly (vinyl alcohol) (PVA) films greatly improved shielding performance over the UV region and were relatively transparent on a white paper background. Due to the large number of ZnO NPs in the central region and, hence, the ease of electron transfer, composite films containing core-shell ZPPs possessed the highest UV blocking ability. ZnO NPs in the outer part of the hollow and Pickering-like ZPPs, on the other hand, facilitated the multiple light scattering according to the difference of refractive indices between the inorganic shell and organic/air core. These results confirm the advantage of structured ZPPs and their potential use as transparent UV shielding fillers.
通过细乳液聚合合成了含有油酸修饰的氧化锌纳米颗粒(OA-ZnO NPs)的聚(苯乙烯-共-丙烯酸)P(St/AA) 氧化锌聚合物纳米颗粒(ZPPs)。通过简单地调整反应物的量,即十二烷基硫酸钠(SDS)表面活性剂、过硫酸钾(KPS)引发剂和二乙烯基苯(DVB)交联剂,ZnO NPs的位置从内部(核)改变到外部(壳),分别导致核壳结构和类Pickering形态。当使用低于或等于临界胶束浓度(CMC)的SDS时,可得到类Pickering ZPPs。在高于CMC时,OA-ZnO NPs在ZPPs中的完全包封呈现出动力学控制的形态。当将KPS从2%降低到0.5-1%时,也会发生向类Pickering ZPPs的转变。而DVB加速了生长中的单体溶胀纳米液滴中的聚合速率和粘度,因此有助于影响颗粒形态的动力学参数,即DVB含量的增加会提高聚合速率。通过用更亲水的单体甲基丙烯酸甲酯替代苯乙烯,获得了中空结构。所有掺入ZPPs的聚乙烯醇(PVA)薄膜在紫外区域的屏蔽性能都有很大提高,并且在白纸背景下相对透明。由于中心区域存在大量的ZnO NPs,因此电子转移容易,含有核壳ZPPs的复合薄膜具有最高的紫外线阻挡能力。另一方面,中空和类Pickering ZPPs外部的ZnO NPs根据无机壳与有机/空气核之间的折射率差异促进了多重光散射。这些结果证实了结构化ZPPs的优势及其作为透明紫外线屏蔽填料的潜在用途。
