在3D打印技术辅助下定制新型带覆膜金属Y形分段气道支架治疗气消化道瘘。

Treatment of aerodigestive fistulas with a novel covered metallic Y-shaped segmented airway stent customized with the assistance of 3D printing.

作者信息

Shan Qungang, Huang Wei, Shang Mingyi, Wang Ziyin, Xia Ning, Xue Qingsheng, Mao Aiwu, Ding Xiaoyi, Wang Zhongmin

机构信息

Department of Interventional Radiology, Ruijin Hospital, Shanghai Jiao Tong University School of Medicine, Shanghai, China.

Department of Interventional Radiology, Tongren Hospital, Shanghai Jiao Tong University School of Medicine, Shanghai, China.

出版信息

Ann Transl Med. 2021 Jul;9(13):1051. doi: 10.21037/atm-21-733.

Abstract

BACKGROUND

The management of aerodigestive fistula remains challenging. An airway stent that matches well with the individual geometry of the airway is needed for the treatment of the aerodigestive fistula. This study aimed to evaluate the feasibility of a novel covered metallic segmented Y-shaped airway stent customized with the assistance of 3D printing in aerodigestive fistulas involving the carina and distal bronchi and to compare the flexibility of the novel stent with the conventional wholly knitted stent.

METHODS

In the flexibility study, we measured the longitudinal bending force and spring-back force of the segmented stent and wholly knitted stent. Patient-specific stents that were individually customized with the assistance of 3D printing technology were implanted in 26 patients with aerodigestive fistulas. The technical success, clinical success, Karnofsky performance status (KPS), and stent-related complications were recorded.

RESULTS

The bending force and spring-back force of the segmented stent were significantly lower than those of the wholly knitted stent. Stent deployment was technically successful in all patients. Clinical success was obtained in 21 patients. The KPS of patients after the stenting procedure improved significantly compared with that before stenting (P<0.001). During follow-up, granulation tissue proliferation, sputum retention, stent migration, and intolerance of the stent were found in 2, 5, 1, and 1 patient, respectively.

CONCLUSIONS

The segmented metallic Y-shaped airway stent had greater flexibility than the wholly knitted stent in an setting. Implantation of the segmented stent individually customized with the aid of 3D printing is feasible in treating aerodigestive fistulas involving the carina and bronchi distal to the carina.

摘要

背景

气道消化道瘘的管理仍然具有挑战性。治疗气道消化道瘘需要一种与气道个体几何形状良好匹配的气道支架。本研究旨在评估在3D打印辅助下定制的新型覆膜金属分段Y形气道支架在涉及隆突和远端支气管的气道消化道瘘中的可行性,并比较新型支架与传统全编织支架的柔韧性。

方法

在柔韧性研究中,我们测量了分段支架和全编织支架的纵向弯曲力和回弹力量。在3D打印技术辅助下单独定制的个体化支架被植入26例气道消化道瘘患者体内。记录技术成功率、临床成功率、卡诺夫斯基性能状态(KPS)和支架相关并发症。

结果

分段支架的弯曲力和回弹力量明显低于全编织支架。所有患者的支架置入在技术上均成功。21例患者获得临床成功。支架置入术后患者的KPS较置入前显著改善(P<0.001)。随访期间,分别有2例、5例、1例和1例患者出现肉芽组织增生、痰液潴留、支架移位和支架不耐受。

结论

在这种情况下,分段金属Y形气道支架比全编织支架具有更大的柔韧性。借助3D打印单独定制的分段支架植入治疗涉及隆突和隆突远端支气管的气道消化道瘘是可行的。

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/e7a4/8339849/90b780a71bd6/atm-09-13-1051-f1.jpg
