Dosimetric parameters of the planning target volume (PTV) and organs at risk (OARs) were compared among 3 different radiotherapy (RT) modalities in left breast cancer patients after breast-conserving surgery (BCS). Eleven patients with left breast cancer after BCS were enrolled and underwent CT simulation in the free breathing (FB) and deep inspiration breath-hold (DIBH) position. Three-dimensional conformal RT (3DCRT) and volumetric modulated arc therapy (VMAT) plans were generated for each patient in the DIBH positions. A 3DCRT plan was also created in the FB position. A dose-volume histogram (DVH) was used to analyze each evaluation index of PTV and OARs. The principal outcomes were PTV dose, heart dose, right breast dose, left anterior descending coronary artery (LADCA) dose, and left lung dose. For 3DCRT plans, significant dose reductions were demonstrated in all evaluation parameters of the heart, LADCA, and left lung doses in the DIBH position compared with those in the FB position ( < 0.05). In the DIBH position, significant dose reductions were found in the heart and LADCA in VMAT plans compared to those in 3DCRT plans ( < 0.05). For the right breast, VMAT reduced Dmean significantly (0.32 Gy vs 0.08  Gy,  < 0.01). There were no significant differences between 3DCRT and VMAT plans for the left lung dose in the DIBH position. The indicators of PTV had no significant difference between the 3 plans. DIBH and VMAT could reduce dosimetric parameters of the OARs in left breast cancer patients after BCS. RT plans for left breast cancer after BCS can be optimized by DIBH and VMAT techniques to minimize radiation-induced toxicity.
