Yan Yajie, Yang Yingguo, Liang Mingli, Abdellah Mohamed, Pullerits Tõnu, Zheng Kaibo, Liang Ziqi
Department of Materials Science, Fudan University, Shanghai, 200433, China.
Shanghai Synchrotron Radiation Facility (SSRF), Shanghai Advanced Research Institute & Chinese Academy of Sciences, Shanghai, 201204, China.
Nat Commun. 2021 Nov 15;12(1):6603. doi: 10.1038/s41467-021-26753-3.
Two-dimensional halide perovskites (2D PVSKs) have drawn tremendous attentions owing to their outstanding ambient stability. However, the random orientation of layered crystals severely impedes the out-of-plane carrier transport and limits the solar cell performance. An in-depth understanding coupled with an effective control of the crystallization in 2D PVSKs is the crux for highly efficient and durable devices. In this contribution, we accidentally discovered that the crystallization of 2D PVSKs can be effectively regulated by so-called 'intermittent spin-coating (ISC)' process. Combined analyses of in(ex)-situ grazing-incidence wide-angle X-ray scattering with time-of-flight secondary ion mass spectrometry distinguish the interface initialized bottom-up crystallization upon ISC treatment from the bi-directional one in the conventional spin-coating process, which results in significantly enhanced crystal orientation and thus facilitated carrier transport as confirmed by both electrical measurements and ultrafast spectroscopies. As a result, the p-i-n architecture planar solar cells based on ISC fabricated paradigm PEAMAPbI deliver a respectable efficiency of 11.2% without any treatment, which is three-fold improvement over their spin-coated counterparts and can be further boosted up to 14.0% by NHCl addition, demonstrating the compatibility of ISC method with other film optimization strategies.
二维卤化物钙钛矿(2D PVSKs)因其出色的环境稳定性而备受关注。然而,层状晶体的随机取向严重阻碍了面外载流子传输,并限制了太阳能电池的性能。深入理解并有效控制2D PVSKs中的结晶过程是制造高效耐用器件的关键。在本研究中,我们意外发现二维钙钛矿的结晶可以通过所谓的“间歇旋涂(ISC)”过程得到有效调控。原位掠入射广角X射线散射与飞行时间二次离子质谱联用分析表明,ISC处理后界面引发的自下而上结晶与传统旋涂过程中的双向结晶不同,这导致晶体取向显著增强,从而促进了载流子传输,电学测量和超快光谱学均证实了这一点。结果,基于ISC制造范式PEAMAPbI的p-i-n结构平面太阳能电池在未经任何处理的情况下具有11.2%的可观效率,比旋涂同类电池提高了两倍,通过添加NHCl可进一步提高至14.0%,证明了ISC方法与其他薄膜优化策略的兼容性。
