The influence of gravity on respiratory kinematics during phonation measured by dynamic magnetic resonance imaging.

Respiratory kinematics are important for the regulation of voice production. Dynamic MRI is an excellent tool to study respiratory motion providing high-resolution cross-sectional images. Unfortunately, in clinical MRI systems images can only be acquired in a horizontal subject position, which does not take into account gravitational effects on the respiratory apparatus. To study the effect of body posture on respiratory kinematics during phonation, 8 singers were examined both in an open-configuration MRI with a rotatable gantry and a conventional horizontal MRI system. During dynamic MRI the subjects sang sustained tones at different pitches in both supine and upright body positions. Sagittal images of the respiratory system were obtained at 1-3 images per second, from which 6 anatomically defined distances were extracted to characterize its movements in the anterior, medium and posterior section of the diaphragm as well as the rip cage (diameter at the height of the 3rd and 5th rip) and the anterior-posterior position of the diaphragm cupola. Regardless of body position, singers maintained their general principles of respiratory kinematics with combined diaphragm and thorax muscle activation for breath support. This was achieved by expanding their chest an additional 20% during inspiration when singing in the supine position but not for sole breathing. The diaphragm was cranially displaced in supine position for both singing and breathing and its motion range increased. These results facilitate a more realistic extrapolation of research data obtained in a supine position.
