压力传感器引导的下颌优先正颌手术:上颌-下颌位置准确性和垂直维度可调节性

PSI-Guided Mandible-First Orthognathic Surgery: Maxillo-Mandibular Position Accuracy and Vertical Dimension Adjustability.

作者信息

Badiali Giovanni, Bevini Mirko, Lunari Ottavia, Lovero Elisa, Ruggiero Federica, Bolognesi Federico, Feraboli Liliana, Bianchi Alberto, Marchetti Claudio

机构信息

Department of Maxillo-Facial Surgery, IRCCS Azienda Ospedaliero-Universitaria di Bologna, 40138 Bologna, Italy.

Department of Biomedical and Neuromotor Sciences, University of Bologna, 40126 Bologna, Italy.

出版信息

J Pers Med. 2021 Nov 21;11(11):1237. doi: 10.3390/jpm11111237.

Abstract

In orthognathic surgery, patient-specific osteosynthesis implants (PSIs) represent a novel approach for the reproduction of the virtual surgical planning on the patient. The aim of this study is to analyse the quality of maxillo-mandibular positioning using a hybrid mandible-first mandibular-PSI-guided procedure on twenty-two patients while the upper maxilla was fixed using manually bent stock titanium miniplates. The virtual surgical plan was used to design PSIs and positioning guides, which were then 3D printed using biocompatible materials. A Cone Beam Computed Tomography (CBCT) scan was performed one month after surgery and postoperative facial skeletal models were segmented for comparison against the surgical plan. A three-dimensional cephalometric analysis was carried out on both planned and obtained anatomies. A Spearman correlation matrix was computed on the calculated discrepancies in order to achieve a more comprehensive description of maxillo-mandibular displacement. Intraoperatively, all PSIs were successfully applied. The procedure was found to be accurate in planned maxillo-mandibular positioning reproduction, while maintaining a degree of flexibility to allow for aesthetics-based verticality correction in a pitch range between -5.31 and +1.79 mm. Such a correction did not significantly affect the achievement of planned frontal symmetry.

摘要

在正颌外科手术中,定制接骨植入物(PSIs)是一种将虚拟手术规划重现于患者身上的新方法。本研究旨在分析在22例患者中采用下颌优先的混合下颌-PSI引导程序进行上颌-下颌定位的质量,而上颌则使用手工弯曲的库存钛微型钢板固定。虚拟手术计划用于设计PSIs和定位导板,然后使用生物相容性材料进行3D打印。术后一个月进行锥形束计算机断层扫描(CBCT),并对术后面部骨骼模型进行分割,以便与手术计划进行比较。对计划和实际的解剖结构进行三维头影测量分析。计算计算差异的Spearman相关矩阵,以更全面地描述上颌-下颌移位。术中,所有PSIs均成功应用。该程序在计划的上颌-下颌定位重现方面被发现是准确的,同时保持一定程度的灵活性,以便在-5.31至+1.79mm的俯仰范围内基于美学进行垂直校正。这种校正并未显著影响计划的正面对称性的实现。

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/66e4/8622626/fa0006483ea9/jpm-11-01237-g001.jpg
