Sun Laixi, Shao Ting, Xu Jianfeng, Zhou Xiangdong, Ye Xin, Huang Jin, Bai Jian, Jiang Xiaodong, Zheng Wanguo, Yang Liming
Research Centre of Laser Fusion, China Academy of Engineering Physics Mianyang 621900 China
State Key Laboratory of Modern Optical Instrumentation, Zhejiang University Hangzhou 310027 China.
RSC Adv. 2018 Sep 18;8(57):32417-32422. doi: 10.1039/c8ra06759g.
HF-based etching has been successful in mitigating damage precursors on the surface of fused silica optics used in high power lasers. However, wet etching generally leaves an etching trace leading to surface roughness, which seriously degrades laser beam quality (, transmission loss and wave-front degradation). A way of addressing this issue is to apply plasma etching as a preprocessing step before HF etching, but so far very few studies have provided a practical scheme for engineering applications. In this work, we proposed a novel two-step scheme by combining reactive ion beam etching with dynamic chemical etching techniques. We demonstrate the combined scheme is capable of tracelessly mitigating the laser damage precursors on a fused silica surface. The 0% probability damage threshold obtained by combined etching is 1.4 times higher than that obtained by HF-based etching. The study opens a new approach towards high damage-resistant optics manufacturing and provides the potential possibility of exploring extreme interactions between high-power lasers and matter.
基于氢氟酸(HF)的蚀刻已成功减轻了高功率激光器中使用的熔融石英光学元件表面的损伤前驱体。然而,湿法蚀刻通常会留下蚀刻痕迹,导致表面粗糙度,这严重降低了激光束质量(包括传输损耗和波前退化)。解决这个问题的一种方法是在HF蚀刻之前将等离子体蚀刻作为预处理步骤,但到目前为止,很少有研究提供工程应用的实用方案。在这项工作中,我们提出了一种将反应离子束蚀刻与动态化学蚀刻技术相结合的新型两步方案。我们证明了该组合方案能够无痕减轻熔融石英表面的激光损伤前驱体。通过组合蚀刻获得的0%概率损伤阈值比基于HF蚀刻获得的阈值高1.4倍。该研究为制造高抗损伤光学元件开辟了一条新途径,并为探索高功率激光器与物质之间的极端相互作用提供了潜在可能性。
