Computational fluid dynamics simulation experimental verification and analysis of droplets deposition behaviour on vibrating pear leaves.

BACKGROUND

The interaction between canopy and droplets is very important in the process of crop spraying. During the actual air-assisted application process, air-mist flow inevitably disturbs the leaves before droplets reaching them, which will also affect the final deposition state of the droplets on the leaf. Currently, researches on the interaction between droplets and the target leaf surface mainly focuses on the deposition behaviour on the surface of stationary target leaves rather than the dynamic leaves. Therefore, the deposition characteristics after the collision between the droplets and dynamic leaves are important for practical application and worth further study.

RESULTS

Computational fluid dynamics simulations were performed to characterise the surface roughness, contact angle, and mechanical vibration. The interaction platform between the droplet and the vibrating pear leaf was built for experimental verification under laboratory conditions. The simulation results are in good agreement with the experimental results, which revealed the main reason for the droplet spreading and sliding was the inertial force generated by the relative velocity. It also indicated that the pear leaf vibration can improve the deposition of low-velocity and small droplets, which is different from that of static pear leaves.

CONCLUSION

The deposition effect of droplets in vibrating pear leaves was investigated. This study also provides a simulation method for the collision between a vibrating leaf and moving droplets, and provides reference for the study of droplet deposition characteristics under the vibration of fruit trees.
