School of Life Sciences, Jiangsu University, Zhenjiang 212013, China.
State Key Laboratory of Tea Plant Biology and Utilization, Anhui Agricultural University, No. 130 Changjiang West Road, Hefei 230036, China.
Biosensors (Basel). 2022 Sep 9;12(9):745. doi: 10.3390/bios12090745.
Tea is an important economic crop and health beverage in China. The presence of heavy metal ions in tea poses a significant threat to public health. Here, we prepared an aptamer biosensor labelled with AIEgen nanospheres to detect Pb in tea. The dsDNA modified by amino and phosphoric acid was combined with the carboxylated AIEgen NPs to form AIEgen-DNA with a fluorescence group, which was then fixed to the surface of Zr-MOFs to quench the fluorescence of AIEgen NPs. At the same time, PEG was added to remove nonspecific adsorption. Then Pb was added to cut the DNA sequences containing the cutting sites, and AIEgen NPs and part of the DNA sequences were separated from the Zr-MOFs surface to recover the fluorescence. By comparing the fluorescence changes before and after adding Pb, the detection limit of Pb can reach 1.70 nM. The fluorescence sensor was applied to detect Pb in tea, and the detection results showed that the tea purchased on the market did not contain the concentration of Pb within the detection range. This study provides new insights into monitoring food and agriculture-related pollutants based on fluorescent biosensors.
茶是中国重要的经济作物和健康饮品。茶叶中重金属离子的存在对公众健康构成了重大威胁。在这里,我们制备了一种标记有 AIEgen 纳米球的适体生物传感器,用于检测茶中的 Pb。经氨基和磷酸修饰的 dsDNA 与羧基化的 AIEgen NPs 结合形成带有荧光基团的 AIEgen-DNA,然后将其固定在 Zr-MOFs 表面上,以猝灭 AIEgen NPs 的荧光。同时,添加 PEG 以去除非特异性吸附。然后加入 Pb 以切割含有切割位点的 DNA 序列,AIEgen NPs 和部分 DNA 序列从 Zr-MOFs 表面分离,以恢复荧光。通过比较加入 Pb 前后的荧光变化,可以达到检测 Pb 的检出限为 1.70 nM。该荧光传感器用于检测茶中的 Pb,检测结果表明,市场上购买的茶叶中不含检测范围内的 Pb 浓度。本研究为基于荧光生物传感器监测食品和农业相关污染物提供了新的思路。
