A predictive model for the critical shoulder angle based on a three-dimensional analysis of scapular angular and linear morphometrics.

BACKGROUND

The purpose of this study was to define the features of scapular morphology that are associated with changes in the critical shoulder angle (CSA) by developing the best predictive model for the CSA based on multiple potential explanatory variables, using a completely 3D assessment.

METHODS

3D meshes were created from CT DICOMs using InVesalius (Vers 3.1.1, RTI [Renato Archer Information Technology Centre], Brazil) and Meshmixer (3.4.35, Autodesk Inc., San Rafael, CA). The analysis included 17 potential angular, weighted linear and area measurements. The correlation of the explanatory variables with the CSA was investigated with the Pearson's correlation coefficient. Using multivariable linear regression, the approach for predictive model-building was leave-one-out cross-validation and best subset selection.

RESULTS

Fifty-three meshes were analysed. Glenoid inclination (GI) and coronal plane angulation of the acromion (CPAA) [Pearson's r: 0.535; -0.502] correlated best with CSA. The best model (adjusted R-squared value 0.67) for CSA prediction contained 10 explanatory variables including glenoid, scapular spine and acromial factors. CPAA and GI were the most important based on their distribution, estimate of coefficients and loss in predictive power if removed.

CONCLUSIONS

The relationship between scapular morphology and CSA is more complex than the concept of it being dictated solely by GI and acromial horizontal offset and includes glenoid, scapular spine and acromial factors of which CPAA and GI are most important. A further investigation in a closely defined cohort with rotator cuff tears is required before drawing any clinical conclusions about the role of surgical modification of scapular morphology.

LEVEL OF EVIDENCE

Level 4 retrospective observational cohort study with no comparison group.
