Influence of Adhesive Layer Thickness on the Effectiveness of Reinforcing Thin-Walled Steel Beams with CFRP Tapes-A Pilot Study.

When reinforcing thin-walled steel members with composite tapes, two issues often overlooked in published scientific papers should be considered, namely the correct thickness of the adhesive layer and the optimum bond length of the CFRP tape. In this article, the authors focused on the first of these issues. For this purpose, eight beams with a thin-walled box cross-section and a length of 3 m were subjected to bending in a four-point scheme. Six beams were reinforced with Sika CarboDur S512 composite tape, and two beams without reinforcement were tested as reference members. Three thicknesses of the adhesive layer (SikaDur-30) were analyzed: 0.6 mm, 1.3 mm and 1.75 mm. In addition to examining the effect of the thickness of the adhesive layer on displacements and deformations of thin-walled steel members, the load value at which the composite tape peeled off was also analyzed. Numerical analyses were then carried out in Abaqus, the outcomes of which showed good agreement with the laboratory results. Both numerical and laboratory results have shown that the thickness of the adhesive layer had a minor effect on the reduction in deformation and displacement of the tested beams. At the same time, with the increase in the thickness of the adhesive layer, the value of the load at which the CFRP tapes detached from the beam surface significantly decreased.
