Department of Electrical and Computer Engineering, Aarhus University, Aarhus, Denmark.
Department of Energy Conversion and Storage, Technical University of Denmark (DTU), Lyngby, Denmark.
Adv Sci (Weinh). 2023 Feb;10(6):e2205942. doi: 10.1002/advs.202205942. Epub 2023 Jan 3.
The electrical properties of pristine fluoropolymers are inferior due to their low polar crystalline phase content and rigid dipoles that tend to retain their fixed moment and orientation. Several strategies, such as electrospinning, electrohydrodynamic pulling, and template-assisted growing, have been proven to enhance the electrical properties of fluoropolymers; however, these techniques are mostly very hard to scale-up and expensive. Here, a facile interfacial engineering approach based on amine-functionalized graphene oxide (AGO) is proposed to manipulate the intermolecular interactions in poly(vinylidenefluoride-trifluoroethylene) (PVDF-TrFE) to induce β-phase formation, enlarge the lamellae dimensions, and align the micro-dipoles. The coexistence of primary amine and hydroxyl groups on AGO nanosheets offers strong hydrogen bonding with fluorine atoms, which facilitates domain alignment, resulting in an exceptional remnant polarization of 11.3 µC cm . PVDF-TrFE films with 0.1 wt.% AGO demonstrate voltage coefficient, energy density, and energy-harvesting figure of merit values of 0.30 Vm N , 4.75 J cm , and 14 pm J , respectively, making it outstanding compared with state-of-the-art ceramic-free ferroelectric films. It is believed that this work can open-up new insights toward structural and morphological tailoring of fluoropolymers to enhance their electrical and electromechanical performance and pave the way for their industrial deployment in next-generation wearables and human-machine interfaces.
原始氟聚合物的电性能较差,因为其低极性结晶相含量和刚性偶极子倾向于保持其固定的矩和取向。已经证明,几种策略,如静电纺丝、电动力学拉伸和模板辅助生长,可以提高氟聚合物的电性能;然而,这些技术大多非常难以扩大规模且昂贵。在这里,提出了一种基于胺功能化氧化石墨烯(AGO)的简便界面工程方法,以操纵聚(偏二氟乙烯-三氟乙烯)(PVDF-TrFE)中的分子间相互作用,诱导β相形成,扩大层片尺寸,并使微偶极子取向。GO 纳米片上的伯胺和羟基共存提供了与氟原子的强氢键,这有助于畴取向,从而产生 11.3 µC cm 的异常剩余极化。含 0.1 wt.%AGO 的 PVDF-TrFE 薄膜的电压系数、能量密度和能量收集优值分别为 0.30 Vm N、4.75 J cm 和 14 pm J,与最先进的无陶瓷铁电薄膜相比,性能优异。相信这项工作可以为氟聚合物的结构和形态设计提供新的见解,以提高其电性能和机电性能,并为其在下一代可穿戴设备和人机界面中的工业应用铺平道路。
