Liu Qian, Chen Lixin, Liu Xiaohua, Peng Guijuan, Zhong Xiaofang, Sheng Yuanyuan, Luo Shuyu, Huang Yuxiang, Xu Jinfeng, Liu Yingying
Shenzhen Medical Ultrasound Engineering Center, Department of Ultrasound, Shenzhen People's Hospital, The Second Clinical Medical College, Jinan University, Shenzhen, China.
The First Affiliated Hospital, Southern University of Science and Technology, Shenzhen, China.
Quant Imaging Med Surg. 2023 Apr 1;13(4):2248-2261. doi: 10.21037/qims-22-534. Epub 2023 Feb 9.
We investigated the application value of no-invasive myocardial work in evaluating left ventricular (LV) function in patients with hyperthyroidism.
Sixty-five patients with an initial hyperthyroidism diagnosis were sorted into tachycardia (group TH1, n=31) and without tachycardia (group TH2, n=34) groups. Thirty healthy participants served as the control group (group CON). LV strain parameters and LV myocardial work parameters were evaluated at rest. Each parameter's value in identifying myocardial damage was analyzed using receiver operating characteristic curves. The correlation of myocardial work parameters with global longitudinal strain (GLS), longitudinal peak strain dispersion (normalized by heart rate, PSD), and systolic blood pressure (SBP) was analyzed.
There was no difference in classic echocardiographic parameters between the groups. Compared with that in group CON, GLS decreased in groups TH1 and TH2 (TH1 17.99%±2.21% and TH2: 19.00%±2.85% 20.27%±1.49%; both P<0.05); there was no significant difference between groups TH1 and TH2. PSD increased in groups TH1 and TH2 (TH1 73.13±19.51 ms and TH2 55.06±17.03 44.13±8.65 ms; both P<0.05); it was higher in group TH1 than in group TH2 (P<0.05). Myocardial global work efficiency (GWE) decreased in groups TH1 and TH2 {TH1 95% [interquartile range (IQR), 94-95%] and TH2 96% (IQR, 95-97%) 97% (IQR, 96-97%); both P<0.05}; it was lower in group TH1 than in group TH2 (P<0.05). Global constructive work (GCW) decreased in group TH1 (1,865.29±284.13 2,030.33±252.52 mmHg%; P<0.05), but was not different from that in group TH2; there was no difference between groups TH2 and CON. Global wasted work (GWW) increased in groups TH1 and TH2 [TH1 83.00 (IQR, 74.00-97.00) mmHg% and TH2 69.50 (IQR, 51.25-84.25) 50.50 (IQR, 40.75-65.25) mmHg%; both P<0.05]; it was higher in group TH1 than in group TH2 (P<0.05). The area under the GWE curve was the largest (area under the curve =0.835), and the optimal cutoff point was 96.5%, with a sensitivity of 0.83 and a specificity of 0.70. GWE and GCW were positively correlated with GLS and negatively correlated with PSD. GWW was negatively correlated with GLS and positively correlated with PSD. In group CON, GCW and GWW were positively correlated with SBP; GWE was not correlated with SBP. In groups TH1 and TH2, GCW was positively correlated with SBP, but not with GWW or GWE.
Hyperthyroidism can significantly decrease the GWE and increase GWW of the left ventricle. This change is more pronounced in patients with tachycardia. Myocardial work could be a novel method for the evaluation of LV myocardial function in patients with hyperthyroidism.
我们研究了无创心肌做功在评估甲状腺功能亢进症患者左心室(LV)功能中的应用价值。
将65例初诊为甲状腺功能亢进症的患者分为心动过速组(TH1组,n = 31)和无心动过速组(TH2组,n = 34)。30名健康参与者作为对照组(CON组)。静息状态下评估左心室应变参数和左心室心肌做功参数。使用受试者工作特征曲线分析每个参数在识别心肌损伤中的价值。分析心肌做功参数与整体纵向应变(GLS)、纵向峰值应变离散度(心率标准化,PSD)和收缩压(SBP)的相关性。
各组间经典超声心动图参数无差异。与CON组相比,TH1组和TH2组的GLS降低(TH1组为17.99%±2.21%,TH2组为19.00%±2.85%,CON组为20.27%±1.49%;P均<0.05);TH1组和TH2组之间无显著差异。TH1组和TH2组的PSD增加(TH1组为73.13±19.51 ms,TH2组为55.06±17.03,CON组为44.13±8.65 ms;P均<0.05);TH1组高于TH2组(P<0.05)。TH1组和TH2组的心肌整体做功效率(GWE)降低{TH1组为95%[四分位间距(IQR),94 - 95%],TH2组为96%(IQR,95 - 97%),CON组为97%(IQR,96 - 97%);P均<0.05};TH1组低于TH2组(P<0.05)。TH1组的整体建设性做功(GCW)降低(1,865.29±284.13 vs 2,030.33±252.52 mmHg%;P<0.05),但与TH2组无差异;TH2组与CON组之间无差异。TH1组和TH2组的整体浪费做功(GWW)增加[TH1组为83.00(IQR,74.00 - 97.00)mmHg%,TH2组为69.50(IQR,51.25 - 84.25),CON组为50.50(IQR,40.75 - 65.25)mmHg%;P均<0.05];TH1组高于TH2组(P<0.05)。GWE曲线下面积最大(曲线下面积 = 0.835),最佳截断点为96.5%,敏感性为0.83,特异性为0.70。GWE和GCW与GLS呈正相关,与PSD呈负相关。GWW与GLS呈负相关,与PSD呈正相关。在CON组中,GCW和GWW与SBP呈正相关;GWE与SBP无相关性。在TH1组和TH2组中,GCW与SBP呈正相关,但与GWW或GWE无相关性。
甲状腺功能亢进症可显著降低左心室的GWE并增加GWW。这种变化在心动过速患者中更为明显。心肌做功可能是评估甲状腺功能亢进症患者左心室心肌功能的一种新方法。
