基于共价有机框架可见光诱导类似酶活性的尿酸比色检测的智能手机即时检测平台设计。

Design of Smartphone-Assisted Point-of-Care Platform for Colorimetric Sensing of Uric Acid via Visible Light-Induced Oxidase-Like Activity of Covalent Organic Framework.

机构信息

College of Sciences, Northeastern University, Shenyang 110819, China.

出版信息

Sensors (Basel). 2023 Apr 11;23(8):3881. doi: 10.3390/s23083881.


DOI:10.3390/s23083881
PMID:37112222
原文链接:https://pmc.ncbi.nlm.nih.gov/articles/PMC10141710/
Abstract

Monitoring of uric acid (UA) levels in biological samples is of great significance for human health, while the development of a simple and effective method for the precise determination of UA content is still challenging. In the present study, a two-dimensional (2D) imine-linked crystalline pyridine-based covalent organic framework (TpBpy COF) was synthesized using 2,4,6-triformylphloroglucinol (Tp) and [2,2'-bipyridine]-5,5'-diamine (Bpy) as precursors via Schiff-base condensation reactions and was characterized with scanning electron microscopy (SEM), Energy dispersive X-ray spectroscopy (EDS), Powder X-ray diffraction (PXRD), Fourier transform infrared (FT-IR) spectroscopy, and Brunauer-Emmett-Teller (BET) assays. The as-synthesized TpBpy COF exhibited excellent visible light-induced oxidase-like activity, ascribed to the generation of superoxide radicals (O) by photo-generated electron transfer. TpBpy COF could efficiently oxidase the colorless substrate 3,3',5,5'-tetramethylbenzydine (TMB) into blue oxidized TMB (oxTMB) under visible light irradiation. Based on the color fade of the TpBpy COF + TMB system by UA, a colorimetric procedure was developed for UA determination with a detection limit of 1.7 μmol L. Moreover, a smartphone-based sensing platform was also constructed for instrument-free and on-site detection of UA with a sensitive detection limit of 3.1 μmol L. The developed sensing system was adopted for UA determination in human urine and serum samples with satisfactory recoveries (96.6-107.8%), suggesting the potential practical application of the TpBpy COF-based sensor for UA detection in biological samples.

摘要

监测生物样本中的尿酸 (UA) 水平对人类健康具有重要意义,而开发一种简单有效的方法来精确测定 UA 含量仍然具有挑战性。在本研究中,使用 2,4,6-三(三氟甲基)苯甲醛(Tp)和[2,2'-联吡啶]-5,5'-二胺(Bpy)作为前体,通过席夫碱缩合反应合成了二维(2D)亚胺键合的结晶吡啶基共价有机框架(TpBpy COF),并通过扫描电子显微镜(SEM)、能量色散 X 射线光谱(EDS)、粉末 X 射线衍射(PXRD)、傅里叶变换红外(FT-IR)光谱和 Brunauer-Emmett-Teller(BET)分析进行了表征。所合成的 TpBpy COF 表现出优异的可见光诱导氧化酶样活性,归因于光生电子转移产生超氧自由基(O)。TpBpy COF 可以在可见光照射下将无色底物 3,3',5,5'-四甲基联苯胺(TMB)有效地氧化成蓝色氧化 TMB(oxTMB)。基于 UA 使 TpBpy COF+TMB 体系的颜色褪色,开发了一种用于 UA 测定的比色法,检测限为 1.7 μmol L。此外,还构建了基于智能手机的传感平台,用于无仪器和现场检测 UA,具有敏感的检测限 3.1 μmol L。该开发的传感系统用于人尿和血清样品中的 UA 测定,回收率令人满意(96.6-107.8%),表明基于 TpBpy COF 的传感器在生物样品中检测 UA 具有潜在的实际应用。

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/736a/10141710/2d02368c72a3/sensors-23-03881-g006.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/736a/10141710/ba55fb109367/sensors-23-03881-sch001.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/736a/10141710/59dca184cbe2/sensors-23-03881-g001.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/736a/10141710/627897a00797/sensors-23-03881-g002.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/736a/10141710/000da15162c3/sensors-23-03881-g003.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/736a/10141710/f5ac17185245/sensors-23-03881-g004.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/736a/10141710/961fa6e21f61/sensors-23-03881-g005.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/736a/10141710/2d02368c72a3/sensors-23-03881-g006.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/736a/10141710/ba55fb109367/sensors-23-03881-sch001.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/736a/10141710/59dca184cbe2/sensors-23-03881-g001.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/736a/10141710/627897a00797/sensors-23-03881-g002.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/736a/10141710/000da15162c3/sensors-23-03881-g003.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/736a/10141710/f5ac17185245/sensors-23-03881-g004.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/736a/10141710/961fa6e21f61/sensors-23-03881-g005.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/736a/10141710/2d02368c72a3/sensors-23-03881-g006.jpg
