基于纳米孔阵列的光学无标记生物传感器对胶质母细胞瘤与肿瘤周围组织的鉴别。
Discriminating Glioblastoma from Peritumoral Tissue by a Nanohole Array-Based Optical and Label-Free Biosensor.
机构信息
Department of Neurological Surgery and Spine Unit, Hospital Universitario Marqués de Valdecilla, 39008 Santander, Spain.
Department of Applied Physics, Faculty of Sciences, Universidad de Cantabria, 39005 Santander, Spain.
出版信息
Biosensors (Basel). 2023 May 30;13(6):591. doi: 10.3390/bios13060591.
In glioblastoma (GBM) patients, maximal safe resection remains a challenge today due to its invasiveness and diffuse parenchymal infiltration. In this context, plasmonic biosensors could potentially help to discriminate tumor tissue from peritumoral parenchyma based on differences in their optical properties. A nanostructured gold biosensor was used ex vivo to identify tumor tissue in a prospective series of 35 GBM patients who underwent surgical treatment. For each patient, two paired samples, tumor and peritumoral tissue, were extracted. Then, the imprint left by each sample on the surface of the biosensor was individually analyzed, obtaining the difference between their refractive indices. The tumor and non-tumor origins of each tissue were assessed by histopathological analysis. The refractive index (RI) values obtained by analyzing the imprint of the tissue were significantly lower ( = 0.0047) in the peritumoral samples (1.341, Interquartile Range (IQR) 1.339-1.349) compared with the tumor samples (1.350, IQR 1.344-1.363). The ROC (receiver operating characteristic) curve showed the capacity of the biosensor to discriminate between both tissues (area under the curve, 0.8779, < 0.0001). The Youden index provided an optimal RI cut-off point of 0.003. The sensitivity and specificity of the biosensor were 81% and 80%, respectively. Overall, the plasmonic-based nanostructured biosensor is a label-free system with the potential to be used for real-time intraoperative discrimination between tumor and peritumoral tissue in patients with GBM.
在胶质母细胞瘤(GBM)患者中,由于其侵袭性和弥漫性实质浸润,最大限度地安全切除仍然是一个挑战。在这种情况下,等离子体生物传感器有可能根据其光学性质的差异帮助区分肿瘤组织和肿瘤周围实质。在一项前瞻性的 35 例接受手术治疗的 GBM 患者系列研究中,使用纳米结构金生物传感器来识别肿瘤组织。对于每个患者,提取了两个配对样本,肿瘤和肿瘤周围组织。然后,单独分析每个样本在生物传感器表面留下的印记,获得它们折射率之间的差异。通过组织学分析评估每个组织的肿瘤和非肿瘤来源。通过分析组织印记获得的折射率(RI)值在肿瘤周围样本中明显较低(= 0.0047)(1.341,四分位距(IQR)1.339-1.349)与肿瘤样本相比(1.350,IQR 1.344-1.363)。ROC(接受者操作特征)曲线显示了生物传感器区分两种组织的能力(曲线下面积,0.8779,<0.0001)。约登指数提供了一个最佳的 RI 截断值为 0.003。生物传感器的灵敏度和特异性分别为 81%和 80%。总的来说,基于等离子体的纳米结构生物传感器是一种无标记系统,有可能用于实时术中区分 GBM 患者的肿瘤和肿瘤周围组织。
