Hygienic Safety ⋅ Materials Research Group, World Institute of Kimchi, Gwangju, Republic of Korea.
Department of Biology and Department of Life and Nanopharmaceutical Sciences, Kyung Hee University, Seoul, Republic of Korea.
PeerJ. 2023 Jul 17;11:e15680. doi: 10.7717/peerj.15680. eCollection 2023.
Ultramicrobacteria (UMB), also known as ultra-small bacteria, are tiny bacteria with a size less than 0.1 µm. They have a high surface-to-volume ratio and are found in various ecosystems, including the human body. UMB can be classified into two types: one formed through cell contraction and the other that maintains a small size. The ultra-small microbiome (USM), which may contain UMB, includes all bacteria less than 0.2 µm in size and is difficult to detect with current methods. However, it poses a potential threat to food hygiene, as it can pass through sterilization filters and exist in a viable but non-culturable (VBNC) state. The data on the USM of foods is limited. Some bacteria, including pathogenic species, are capable of forming UMB under harsh conditions, making it difficult to detect them through conventional culture techniques.
The study described above focused on exploring the diversity of USM in fermented cabbage samples from three different countries (South Korea, China, and Germany). The samples of fermented cabbage (kimchi, suancai, and sauerkraut) were purchased and stored in chilled conditions at approximately 4 °C until filtration. The filtration process involved two steps of tangential flow filtration (TFF) using TFF cartridges with different pore sizes (0.2 µm and 100 kDa) to separate normal size bacteria (NM) and USM. The USM and NM isolated via TFF were stored in a refrigerator at 4 °C until DNA extraction. The extracted DNA was then amplified using PCR and the full-length 16S rRNA gene was sequenced using single-molecule-real-time (SMRT) sequencing. The transmission electron microscope (TEM) was used to confirm the presence of microorganisms in the USM of fermented cabbage samples.
To the best of our knowledge, this is the first study to identify the differences between USM and NM in fermented cabbages. Although the size of the USM (average 2,171,621 bp) was smaller than that of the NM (average 15,727,282 bp), diversity in USM (average ' = 1.32) was not lower than that in NM (average ' = 1.22). In addition, some members in USM probably underwent cell shrinkage due to unfavorable environments, while others maintained their size. Major pathogens were not detected in the USM in fermented cabbages. Nevertheless, several potentially suspicious strains (genera and ) were detected. Our method can be used to screen food materials for the presence of USM undetectable via conventional methods. USM and NM were efficiently separated using tangential flow filtration and analyzed via single-molecule real-time sequencing. The USM of fermented vegetables exhibited differences in size, diversity, and composition compared with the conventional microbiome. This study could provide new insights into the ultra-small ecosystem in fermented foods, including fermented cabbages.
超微细菌(UMB),也称为超小型细菌,是一种尺寸小于 0.1 µm 的微小细菌。它们具有高的表面积与体积比,存在于各种生态系统中,包括人体。UMB 可以分为两种类型:一种是通过细胞收缩形成的,另一种则保持较小的尺寸。超小型微生物组(USM)可能包含 UMB,包括所有小于 0.2 µm 的细菌,目前的方法难以检测到。然而,它对食品卫生构成了潜在威胁,因为它可以通过消毒过滤器并处于存活但不可培养(VBNC)状态。关于食品 USM 的数据有限。一些细菌,包括致病性物种,能够在恶劣条件下形成 UMB,因此很难通过常规培养技术检测到它们。
本研究主要探讨了来自三个不同国家(韩国、中国和德国)的发酵白菜样本中超小型微生物组(USM)的多样性。购买发酵白菜(泡菜、酸菜和酸白菜)样本并在约 4°C 的冷藏条件下储存,直到过滤。过滤过程涉及两步切向流过滤(TFF),使用具有不同孔径(0.2 µm 和 100 kDa)的 TFF 试剂盒分离正常大小的细菌(NM)和 USM。通过 TFF 分离的 USM 和 NM 储存在 4°C 的冰箱中,直到提取 DNA。提取的 DNA 然后通过 PCR 扩增,并使用单分子实时(SMRT)测序对全长 16S rRNA 基因进行测序。透射电子显微镜(TEM)用于确认发酵白菜样本中超小型微生物组中微生物的存在。
据我们所知,这是首次鉴定发酵白菜中超小型微生物组与 NM 之间差异的研究。尽管 USM 的大小(平均 2,171,621 bp)小于 NM 的大小(平均 15,727,282 bp),但 USM 的多样性(平均值 '= 1.32)并不低于 NM 的多样性(平均值 '= 1.22)。此外,由于环境不利,USM 中的一些成员可能经历了细胞收缩,而其他成员则保持其大小。在发酵白菜的 USM 中未检测到主要病原体。然而,检测到了一些潜在可疑的菌株(属 和 )。我们的方法可用于筛选食品材料中常规方法无法检测到的 USM。通过切向流过滤有效地分离 USM 和 NM,并通过单分子实时测序进行分析。与传统微生物组相比,发酵蔬菜的 USM 在大小、多样性和组成上存在差异。本研究可为发酵食品(包括发酵白菜)中的超小型生态系统提供新的见解。
