Study of the Thermochemical Effect on the Transport and Structural Characteristics of Heterogeneous Ion-Exchange Membranes by Combining the Cell Model and the Fine-Porous Membrane Model.

For the first time, based on the joint application of the fine-porous and cell models, a theoretical analysis of the changing transport and structural characteristics of heterogeneous polymeric ion-exchange membranes (IEMs) MK-40, MA-40, and MA-41 after exposure to elevated temperatures in water and aggressive media (HSO and NaOH solutions), as well as after long-term processing in electrodialyzers of various types, was carried out. The studied membranes are composites of ion-exchange polymers with polyethylene and nylon reinforcing mesh. The external influences provoke the aging of IEMs and the deterioration of their characteristics. The transport properties of IEMs are quantitatively described using five physicochemical parameters: counterion diffusion and equilibrium distribution coefficients in the membrane, characteristic exchange capacity, which depends on the microporosity of ion-exchanger particles, and macroscopic porosity at a known exchange capacity of IEMs. Calculations of the physicochemical parameters of the membranes were performed according to a specially developed fitting technique using the experimental concentration dependences of integral diffusion permeability and specific electrical conductivity, and their model analogs. This made it possible to identify and evaluate changes in the membrane micro- and macrostructure and examine the process of artificial aging of the IEM polymer material due to the abovementioned external impacts.
