Int J Mol Sci. 2023 Nov 11;24(22):16203. doi: 10.3390/ijms242216203.
The need for stable and well-defined magnetic nanoparticles is constantly increasing in biomedical applications; however, their preparation remains challenging. We used two different solvothermal methods (12 h reflux and a 4 min microwave, MW) to synthesize amine-functionalized zinc ferrite (ZnFeO-NH) superparamagnetic nanoparticles. The morphological features of the two ferrite samples were the same, but the average particle size was slightly larger in the case of MW activation: 47 ± 14 nm (Refl.) vs. 63 ± 20 nm (MW). Phase identification measurements confirmed the exclusive presence of zinc ferrite with virtually the same magnetic properties. The Refl. samples had a zeta potential of -23.8 ± 4.4 mV, in contrast to the +7.6 ± 6.8 mV measured for the MW sample. To overcome stability problems in the colloidal phase, the ferrite nanoparticles were embedded in polyvinylpyrrolidone and could be easily redispersed in water. Two PVP-coated zinc ferrite samples were administered (1 mg/mL ZnFeO) in X BalbC mice and were compared as contrast agents in magnetic resonance imaging (MRI). After determining the r1/r2 ratio, the samples were compared to other commercially available contrast agents. Consistent with other SPION nanoparticles, our sample exhibits a concentrated presence in the hepatic region of the animals, with comparable biodistribution and pharmacokinetics suspected. Moreover, a small dose of 1.3 mg/body weight kg was found to be sufficient for effective imaging. It should also be noted that no toxic side effects were observed, making ZnFeO-NH advantageous for pharmaceutical formulations.
在生物医学应用中,对稳定且定义明确的磁性纳米粒子的需求不断增加;然而,它们的制备仍然具有挑战性。我们使用两种不同的溶剂热方法(12 小时回流和 4 分钟微波,MW)来合成胺功能化的锌铁氧体(ZnFeO-NH)超顺磁纳米粒子。两种铁氧体样品的形态特征相同,但 MW 激活的平均粒径略大:47±14nm(Refl.)与 63±20nm(MW)。相鉴定测量证实了仅存在具有几乎相同磁性的锌铁氧体。Refl. 样品的zeta 电位为-23.8±4.4mV,而 MW 样品的测量值为+7.6±6.8mV。为了克服胶体相的稳定性问题,将铁氧体纳米粒子嵌入聚乙烯吡咯烷酮中,并可以很容易地重新分散在水中。两种包覆有 PVP 的锌铁氧体样品(1mg/mL ZnFeO)在 X BalbC 小鼠中给药,并作为磁共振成像(MRI)中的对比剂进行比较。在确定 r1/r2 比值后,将样品与其他市售对比剂进行比较。与其他 SPION 纳米粒子一致,我们的样品在动物的肝区表现出集中存在,具有相似的生物分布和药代动力学。此外,发现 1.3mg/体重 kg 的小剂量足以进行有效的成像。还应注意到,没有观察到毒性副作用,这使得 ZnFeO-NH 有利于药物制剂。
